Northman Type Hydraulic Valve Solenoid Coil 110VAC 50Hz 120VAC 60Hz 33W

Northman Type Hydraulic Valve Solenoid Coil 110VAC 50Hz 120VAC 60Hz 33W

Northman solenoid coil, also known as Northman valve coil, or Northman coil for directional valves. Northman solenoid coil is the main part of Northman hydraulic solenoids. The hydraulic solenoid is the actuator of Northman directional valves. A complete hydraulic solenoid is consist of a solenoid coil and a solenoid tube assembly.

A hydraulic solenoid valve is a solenoid controlled directional valve used in a hydraulic system for opening, closing or changing the direction of flow of the liquid. The valve operates with a solenoid, which is an electric coil wound around a ferromagnetic core at its center. The valve consists of various chambers also called ports. The solenoid is used for sliding the spool within the valve, opening or closing the ports. The spool is the cylindrical component which serves the function of the valve by either blocking or allowing the flow of liquid through these ports, depending upon its position.

Hydraulic solenoid valves are widely used in industries like manufacturing, aerospace, construction and many others that require hydraulic systems.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB20051539
		Voltage	12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
		Power	33W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB20251511
		Voltage	12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
		Power	33W
		Connector Type	DIN 43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB20052203
		Voltage	110VAC, 120VAC, 220VAC, 240VAC
		Power	30W
		Connector Type	DIN43650A
		Insulation Class	H
		Protection Class	IP65

Picture	Dimension	Model	BB20051538
		Voltage	110VAC, 120VAC, 220VAC, 240VAC
		Power	30W
		Connector Type	2 Pins (Plug In Type)
		Insulation Class	H
		Protection Class	IP65

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Vickers Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:
