Northman Type Hydraulic Solenoid Valve Coil AC240V 60Hz AC220V 50Hz 30W

Northman Type Hydraulic Solenoid Valve Coil AC240V 60Hz AC220V 50Hz 30W

Specification:
1. Voltage: 12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
2. Application: For Northman hydraulic solenoid valve
3. Coil No: D12, D24, R110, R120, R220, R240
4. Connector type: DIN 43650A, 2 Pins (Plug In Type), Flying Leads, DEUTCH

Features:

1. The Northman solenoid coil is encapsulated with high quality glass-filled nylon, which has better intensity, rigidity, thermostability, etc.
2. The solenoid bobbin of Northman solenoid coil uses the quality material with 30% glass-filled thermoplastic polyester, which can enhance the thermostability of the solenoid bobbins.
3. Multiple choices of solenoid copper wires, Brando provides solenoid coils with class F, class H, class N copper wires, and the IP grade can reach IP65 and IP67.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB20052203
		Voltage	110VAC, 120VAC, 220VAC, 240VAC
		Power	30W
		Connector Type	DIN43650A
		Insulation Class	H
		Protection Class	IP65

Picture	Dimension	Model	BB20051538
		Voltage	110VAC, 120VAC, 220VAC, 240VAC
		Power	30W
		Connector Type	2 Pins (Plug In Type)
		Insulation Class	H
		Protection Class	IP65

Picture	Dimension	Model	BB20051539
		Voltage	12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
		Power	33W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB20251511
		Voltage	12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
		Power	33W
		Connector Type	DIN 43650A
		Insulation Class	F
		Protection Class	IP65

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Vickers Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
