Vickers Type Hydraulic Solenoid Coil 868982 110V 120V 868983 220V 240V

Vickers Type Hydraulic Solenoid Coil 868982 110V 120V 868983 220V 240V

Brando hydraulic solenoid coils for directional and proportional valves ensure the correct and safe supply of the corresponding control current. Practically all coil voltages are available from stock in a large selection of plug variations. Special voltages and special coil designs are available upon request. The solenoid coil is available in standard voltages of 12, 24, 110, 120, 220 and 240 volts, depending on the power required for the solenoid valve. Thanks to its exceptional winding, the coil is very small has a high power output.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB28646201
		Ref. No	02-337001 (110V/120v) 879143 (220V/240V) 879141 (110V/120V)
		Voltage	110VAC, 120VAC, 220VAC, 240VAC
		Power	26W
		Connector Type	DIN43650A
		Insulation Class	H
		Protection Class	IP65

Picture	Dimension	Model	BB28646202
	​	Ref. No	868982 (110/120V) 868983 (220/240V)
		Voltage	110VAC, 120VAC, 220VAC, 240VAC
		Power	26W
		Connector Type	Flying Leads
		Insulation Class	H
		Protection Class	IP67

Picture	Dimension	Model	BB28785003
		Ref. No	02-337014 (24VDC) 879147 (24VDC) 879149
		Voltage	12VDC, 24VDC
		Power	41W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB28785004
		Ref. No	868988 (24VDC) 868987 (12VDC)
		Voltage	12VDC, 24VDC
		Power	41W
		Connector Type	Flying Leads
		Insulation Class	F
		Protection Class	IP67

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:
