3 Way NC Expresso Machine Parker Solenoid Valve Stem Armature Plunger

3 Way NC Expresso Machine Parker Solenoid Valve Stem Armature Plunger

A solenoid valve consists of 6 components:

* The electromagnet
* The plunger
* The plunger spring
* The plunger gasket
* The main gasket
* The tube assembly
* The valve body

The tube assembly

The tube assembly is a stainless-steel cylinder that serves as a guide for the piston and spring inside. In case of a 2-way valve, this tube is capped at the end. For a 3-way valve, this end is normally open to drain the wastewater.

The plunger gasket

The plunger gasket is located in the bottom of the plunger. This gasket is a part that cannot be serviced. The gasket is compressed to a valve seat of the valve body to seal it.

The plunger

The plunger is made of ferritic stainless steel (this is a magnetic stainless-steel variant, opposed to commonly used “traditional” stainless steel, which is not magnetic). This plunger has a gasket in the bottom to seal the valve seat. On top of the plunger, there is a neck in which the spring is located.

Detailed Images of solenoid valve stem:

Dimension & Data of solenoid valve stem:

Dimension	Model	BAPC314533740
	Function	3/2 Way, Normally Closed
	Seat Connection	M20x1 Thread
	Core Tube Material	Stainless Steel 304
	Seal Material	FKM
	Voltage	All range of AC and DC available
	Customize Service	Provided, Pls show us sample or drawing

Brando Solenoid Valve Stem Production Video:

Solenoid Valve Stem Categories:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 30mm.

*According to tube material: Brass, Stainless Steel

*According to valve application: Our armatures are widely used in pneumatic, hydraulic, fluid control fields, covering textiles, home appliances, automobiles, refrigeration, dust collector and other automation control industries.

Features of Armature Assembly:

The main characteristics of the armature of solenoid valve can be reflected in the following aspects.

1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance

4. Sealing materials can be selected according to your different requirements

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection
