3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger

3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger

  • 3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger
3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC313031360
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Solenoid Valve Stem, Solenoid Valve Plunger, Solenoid Valve Armature Function: 3/2 Way, Normally Closed
Tube OD: 13mm Kind Of Current: AC, DC
Armature Tube Material: Stainless Steel Seal Insert Material: NBR
Connection Type: M25x1 Thread Application Example: KSD DA-Y, DC-Y Series Solenoid Valve
Fitted Valves: DC231Y, DC211Y, DC241Y, DA231Y, DA211Y, DA241Y
High Light:

Water Solenoid Valve Stem

,

Water Solenoid Valve Armature

,

Water Solenoid Valve Plunger

3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger



The solenoid consists of a coil of wire wound in the form of a cylinder around the bobbin. When an electrical current is introduced, it resembles a bar magnet. When energized by an electrical signal, a magnetic field builds up which attracts the movable plunger to the polepiece against the tension of the main plunger spring. When de-energized, the magnetic field dissipates and the plunger returns to its original position, under the action of the main plunger spring.



1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance

4. Sealing materials can be selected according to your different requirements

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection



Detailed Images of solenoid valve stem:

3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger 0



Dimension & Data of solenoid valve stem:

Dimension
Model
BAPC313031360
3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger 1
Function
3/2 Way, Normally Closed
Seat Connection
M25x1 Thread
Core Tube Material
Stainless Steel 304
Seal Material
NBR
Voltage
All range of AC and DC available
Customize Service
Provided,
Pls show us sample or drawing


Brando Solenoid Valve Stem Production Video:

3/2 Way NC KSD DC231Y Water Solenoid Valve Stem Armature Plunger 2



Solenoid Valve Stem Categories:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 30mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application: Our armatures are widely used in pneumatic, hydraulic, fluid control fields, covering textiles, home appliances, automobiles, refrigeration, dust collector and other automation control industries.

photobank (14)photobank (16)photobank (17)photobank (10)

Features of Armature Assembly:



The main characteristics of the armature of solenoid valve can be reflected in the following aspects.



1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance

4. Sealing materials can be selected according to your different requirements

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
