Dust Collector Solenoid Valve Stem Armature Plunger Tube Assembly

Dust Collector Solenoid Valve Stem Armature Plunger Tube Assembly

Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.

The solenoid valve includes an electromagnet which comprises a coil arrangement and an armature driven by the coil arrangement. A control part is provided on the armature, which corresponds to at least one channel aperture to be controlled in a fluid channel, and which is shifted at the control movement of the armature relative to the at least one channel aperture. The armature is formed as a pivot anchor, whose switching movement is a pivotal movement , at which the control part is shifted orthogonally to the longitudinal axis of the coil arrangement.

Detailed Images of Pulse Valve Armature:

Dimension & Data of Pulse Valve Armature:

Dimension	Model	BAPC213043091
	Funtion	2 Way, Normally Closed
	Seat	M16x1 Thread
	Core Tube Material	Stainless Steel
	Seal Material	NBR
	Voltage	AC, DC
	Fitted Coil	Best-Nr.0200
	Fitted Valve	Pulse Valve

Dimension	Model	Best-Nr.0200
	Voltage	24VDC, 220VAC
	Power	18VA, 15W
	Fitted Armature Plunger	BAPC213043001
	Fitted Valve	Pulse Valve
