Pulse Valve Rebuild Kit Solenoid Valve Stem Armature Plunger Assembly

Pulse Valve Rebuild Kit Solenoid Valve Stem Armature Plunger Assembly

The shown is one kind of solenoid stem for pulse jet valve. Brando supply many brand pulse valve repair kit replacement armature, like BFEC (SBFEC), Goyen, ASCO, Turbo, Mecair, Norgren Buschjost, JOIL, AUTEL, Taeha and other Chinese brand. And we also supply related solenoid coils, diaphragms and pulse jet valves.

Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.

Detailed Images of solenoid valve stem:

Dimension & Data of solenoid valve stem:

Dimension	Model	BAPC212037810
	Function	2 Way, Normally Closed
	Seat Connection	M23.8x1 Thread
	Core Tube Material	Stainless Steel 304
	Seal Material	NBR
	Voltage	All range of AC and DC available
	Application Example	Pulse Jet Valve
	Customize Service	Provided, Pls show us sample or drawing

Brando Solenoid Valve Stem Production Video:

Hot Sale Products:

* Solenoid Valve Coil:

* Diaphragm Repair Kit:

* Pulse Jet Valve:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
