1 1/2'' DMF-Z-40S Repair Kit BFEC Pulse Solenoid Valve Stem

1 1/2'' DMF-Z-40S Repair Kit BFEC Pulse Solenoid Valve Stem

This solenoid stem is used for new version BFEC pulse valve repair kit. The related bfec pulse jet valves, solenoid coils and diaphragms are also supply. Welcome to your any inquiry and problem.

The solenoid consists of a coil of wire wound in the form of a cylinder around the bobbin. When an electrical current is introduced, it resembles a bar magnet. When energized by an electrical signal, a magnetic field builds up which attracts the movable plunger to the polepiece against the tension of the main plunger spring. When de-energized, the magnetic field dissipates and the plunger returns to its original position, under the action of the main plunger spring.

In order to be usable on AC current as well as DC, the polepiece contains a shading ring to average the alternating sine wave and minimize AC hum. (Note - It is not necessary to use a shading ring for DC applications as DC current does not produce an alternating wave function.) The flowing media is normally permitted to enter the area between the plunger and plunger guide tube, and caution should be used to assure that these components are compatible with the media when selecting a valve.

BFEC Pulse Valve Armature:

Picture	Dimension	Brando Model	BAPC213553538
		Function	2 Way, Normally Closed
		Seat	Flange
		Core Tube Material	Stainless Steel
		Seal Material	NBR
		Voltage	AC, DC
		Fitted Valve	BFEC Old DMF Series Pulse Valves

Picture	Dimesion	Brando Model	BB13541204
		Voltage	24VDC, 220VAC
		Power	25VA, 20W
		Fitted Armature Plunger	BAPC213050375
		Fitted Valve	BFEC New DMF Series Pulse Valves

Picture	Dimension	Brando Model	BAPC213050375
		Function	2 Way, Normally Closed
		Seat	Flange
		Core Tube Material	Stainless Steel
		Seal Material	NBR
		Voltage	AC, DC
		Fitted Valve	BFEC New DMF Series Pulse Valves

Picture	Dimesion	Brando Model	BB13541204
		Voltage	24VDC, 220VAC
		Power	25VA, 20W
		Fitted Armature Plunger	BAPC213050375
		Fitted Valve	BFEC New DMF Series Pulse Valves

Brando Solenoid Valve Armature Production Video:

Related product supply:

* Solenoid Valve Coil:

* Diaphragm Repair Kit:

* Pulse Jet Valve:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
