3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem
video
3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: K0850
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: ASCO Pulse Valve Armature, ASCO Pulse Valve Plunger, ASCO Pulse Valve Stem Function: 2 Way, Normally Closed
Kind Of Current: AC, DC Armature Tube Material: Stainless Steel
Seal Insert Material: NBR (Nitrile) Connection Type: M23.8x1 Thread
Fitted Solenoid Coil: 400325 Fitted Pulse Valve: SCG353A043, SCG353A44
High Light:

ASCO Solenoid Valve Stem

,

ASCO Pulse Valve Stem

,

ASCO Pulse Valve Armature

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem



This is solenoid valve stem for asco 3/4'' SCG353A043 and 1'' SCG353A044 pulse valve repair kit. When the working current passing through the coil, a magnetic field is generated around the coil. The electromagnetic force drives the moving iron core to overcome the resistance of the spring to move upward, and it is absorbed with the static iron core. When the coil is powered off, the electromagnetic force disappears, and the moving iron core is reset downward under the action of the spring force. The related pulse jet valves, solenoid coils and diaphragms are also supply. Welcome to your any inquiry and problem.



ASCO Pulse Valve Armature:

Picture Dimesion
Brando Model
BAPC211037301
3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 0 3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 1
Reference Number
K0850
Plunger Tube Material
Stainless Steel
Seal Material
NBR
Voltage
DC, AC
Function
2 Way, Normally Closed
Fitted Coil
400325
Fitted Valve
3/4'' SCG353A043,
1'' SCG353A044



Picture Dimesion
Brando Model
BB11036001
3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 2 3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 3
Reference Number
400325
Voltage
24VDC, 48VDC,
24VAC, 48VAC,
115VAC, 230VAC
Fitted Armature Plunger
K0850
Fitted Valve
3/4'' SCG353A043,
1'' SCG353A044



Picture Dimension
Brando Model
BAPC214041405
3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 4 3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 5
Reference Number
K0950
Plunger Tube Material
Stainless Steel
Seal Material
NBR
Voltage
AC, DC
Function
2 Way, Normally Closed
Fitted Coil
400425
Fitted Valve
1 1/2'' SCG353A047,
2'' SCG353A050,
2 1/2'' SCG353A051




Picture Dimesion
Brando Model
BB14040007
3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 6 3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 7
Reference Number
400425
Voltage
24VDC, 48VDC,
24VAC, 48VAC,
115VAC, 230VAC
Fitted Armature Plunger
K0950
Fitted Valve
1 1/2'' SCG353A047,
2'' SCG353A050,
2 1/2'' SCG353A051



Brando Solenoid Valve Armature Production Video:

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 8



Related product supply:



* Solenoid Valve Coil:

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 9

* Diaphragm Repair Kit:

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 10



* Pulse Jet Valve:

3/4'' SCG353A043 Repair Kit ASCO Pulse Solenoid Valve Stem 11



FAQ:



How can you tell if your solenoid is bad?
If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.



What is a solenoid?
A solenoid is an electric coil that is wrapped around a ferromagnetic substance (such as iron) that acts as an electromagnet when the current is passed through it.



How does a solenoid work?
When the electric current is passed through the coil, an electromagnetic field is created. This electromagnetic field causes the plunger to move up or down. This mechanism is used by solenoid valves to open or close the valve.
