3/2 Way NC Stainless Steel Solenoid Valve Armature For N15270 N16381 N16382 N16387

3/2 Way NC Stainless Steel Solenoid Valve Armature For N15270 N16381 N16382 N16387

3/2 Way NC Stainless Steel Solenoid Valve Armature For N15270 N16381 N16382 N16387
video
3/2 Way NC Stainless Steel Solenoid Valve Armature For N15270 N16381 N16382 N16387
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC311640003
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Fittings Guide Tube Outer Diameter: 11.7mm
Installation Height For Coil Assembling: 32.1mm Plunger Seal For Orifice Diameter: 4.5mm
Guide Tube Material: Brass Seal Material: NBR
Mounting Type: Flange Voltage: AC, DC All Available
Position And Way: 3/2 Way Applicable: N15270, N16381, N16382, N16387, N06556 Solenoid Valve
High Light:

NC Solenoid Valve Armature

,

Stainless Steel Solenoid Valve Armature

,

Stainless Steel Tube Armature Assembly

3/2 Way NC Stainless Steel Solenoid Valve Armature For N15270 N16381 N16382 N16387



Automatic condensate drains are essential components in every compressed air treatment system, purging liquid from receiver tanks, water separators, coalescing filters, and air dryers. Auto drains are small and relatively inexpensive, making them easy to overlook, and too often plant operators underestimate the consequences of a drain failure.A simple drain mishap can easily cause thousands of dollars in equipment damage and product spoilage. I’ve seen it happen too many times to count.



Brando provides customized solenoid armature services for various types of solenoid valves.

Our solenoid armature assembly has high quality, precise stroke control, long service life, and a full range of products, including 3/2-way, 2/2-way, normally open, normally closed, and threaded or flanged connection available.

Brando Solenoid plungers are available in numerous designs and have been tested to meet rigorous performance requirements for solenoid valves. These solenoid plungers can be utilized in various applications including, air and fluid power applications, heating and cooling system regulation units, industrial, and automotive applications.



Condition:New
Applicable Industries:Solenoid Valve
Type:Fittings
Place of Origin:Zhejiang, China
Brand Name:Brando
Guide Tube Outer Diameter:11.7mm
Installation Height for Coil Assembling:32.1mm
Plunger Seal for Orifice Diameter:4.5mm
Guide Tube Material:Stainless Steel
Seal Material:NBR
Mounting Type:Flange
Voltage:AC, DC All Available
Position and Way:3/2 Way
Non-working Status:Normally Close
Application:N15270, N16381, N16382, N16387, N06556 solenoid valve



Dimension of BAPC31164003 Armature Assembly:



Dimension of BAPC31164003 Armature Assembly:





Technical Data:

Model Number
BAPC31164003
Guide Tube Outer Diameter
11.7mm
Installation Height for Coil Assembling
32.1mm
Plunger Seal for Orifice Diameter
4.5mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
Flange
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing





Product Features:

1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.

2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.

3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.

4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.

5 Shading ring:
Cooper and silver material available.

6. Washer and retaining nut provided if has demands.



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)


Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
