Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly
video
Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC309031034
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Function: 3 Way, Normally Closed Seat Type: Flange With Oring Groove
Plunger Tube Material: Brass Plunger Tube OD: φ9mm
Seal Material: VITON (FKM) Voltage: AC, DC All Available
High Light:

3/2 Way NC Solenoid Valve Armature

,

Viton Seal Solenoid Valve Armature

,

Solenoid Kit Plunger

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly



Description:

When the working current passing through the coil, a magnetic field is generated around the coil. The electromagnetic force drives the moving iron core to overcome the resistance of the spring to move upward, and it is absorbed with the static iron core.



When the coil is powered off, the electromagnetic force disappears, and the moving iron core is reset downward under the action of the spring force.



During the choose of the Solenoid Armature, you should pay attention to below factors:



1. Working voltage: AC or DC

2. Switching function: 2/2 or 3/2way;

3. De-energized state: Normal close, normal open or Divert

4. Stroke of the matched valve body

5. Valve’s orifice

6. Working environment: working medium, temperature, pressure of pipeline etc



Technical data of Solenoid Valve Armature Assembly:

Model Number
BAPC309031034
Guide Tube Outer Diameter
8.8mm
Installation Height for Coil Assembling
29.0mm
Plunger Seal for Orifice Diameter
4.1mm
Guide Tube Material
Brass
Connection Type
Flange with o-ring groove
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing





Details of Solenoid Valve Armature Assembly:

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly 0

 3 Way Normally Closed                      Flange Seat

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly 1

              Plunger Slot                              NBR Seal





Main dimension of Solenoid Valve Armature Assembly:

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly 2

Brando Factory Production of Solenoid Valve Armature Assembly:

Viton Seal Brass Tube 3/2 Way NC Solenoid Valve Armature Assembly 3



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
