M20 Seat 14.3mm OD Stainless Steel Guide Tube Solenoid Valve Armature

M20 Seat 14.3mm OD Stainless Steel Guide Tube Solenoid Valve Armature

M20 Seat 14.3mm OD Stainless Steel Guide Tube Solenoid Valve Armature
video
M20 Seat 14.3mm OD Stainless Steel Guide Tube Solenoid Valve Armature
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC214338162
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Fittings Guide Tube Outer Diameter: 14.3mm
Installation Height For Coil Assembling: 38.0mm Plunger Seal For Orifice Diameter: 7.8mm
Guide Tube Material: Stainless Steel Seal Material: NBR
Mounting Type: M20 Thread Voltage: AC, DC All Available
Position And Way: 2/2 Way Applicable: Solenoid Valve
High Light:

M20 Seat Solenoid Valve Armature

,

14.3Solenoid Valve Armature

,

2 Way NC Armature Set

M20 Seat 14.3mm OD Stainless Steel Guide Tube Solenoid Plunger Assembly



When an electrical current is passed through the coils windings, it behaves like an electromagnet and the plunger, which is located inside the coil, is attracted towards the centre of the coil by the magnetic flux setup within the coils body, which in turn compresses a small spring attached to one end of the plunger.

◆ A push solenoid is simply a pull. solenoid with a small shaft added through the bottom of the solenoid to provide the push function.
◆ This shaft is a non-magnetic. material and is generally press fit into a hole in the end of the plunger.
◆ The plunger is pulled into the coil.





Condition:New
Applicable Industries:Solenoid Valve
Type:Fittings
Place of Origin:Zhejiang, China
Brand Name:Brando
Guide Tube Outer Diameter:14.3mm
Installation Height for Coil Assembling:38.0mm
Plunger Seal for Orifice Diameter:7.7mm
Guide Tube Material:Stainless Steel
Seal Material:NBR
Mounting Type:M20 Thread
Voltage:AC, DC All Available
Position and Way:2/2 Way
Non-working Status:Normally Close



Dimension of BAPC214338162 Armature Assembly:



Dimension of BAPC214338074 Armature Assembly:





Technical Data:

Model Number
BAPC214338162
Guide Tube Outer Diameter
14.3mm
Installation Height for Coil Assembling
38.0mm
Plunger Seal for Orifice Diameter
7.7mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
M20 Thread
Voltage
All range of AC and DC available
Position and Way
2/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing





Product Features:

1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.

2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.

3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.

4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.

5 Shading ring:
Cooper and silver material available.

6. Washer and retaining nut provided if has demands.



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)


Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
