Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC

Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC

  • Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC
Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BDF240
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Fountain Solenoid Valve Working Fluids: Water
Port Size (inch): 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'' Orifice Size: 15mm To 100mm
Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz) Application: Air Blast Water Fountain, Music Fountain, Dancing Fountain
Operation Mode: 2/2 Way, Normally Closed Body Material: Stainless Steel
Seal Material: NBR, VITON, EPDM Pressure Range: 0.05 To 2.5 MPa
Thread Type: G, NPT, Flanged
High Light:

Air Blast Solenoid Valve

,

IP68 Solenoid Valve

Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC



Product Features:

1. Function: 2 Way, Normally Closed

2. Medium: Water

3. Acting Type: Diaphragm Pilot Operated

4. Operate Pressure: 0.05 to 2.5 MPa

5. Seal Material: NBR for -5∽80℃, Viton for -5∽150℃;

6. Port Size: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''; G ,PT, NPT are available.

7. Solenoid Coil: 12VDC, 24VDC, 24VAC, 120VAC, 240VAC, 110VAC, 220VAC; IP68, ED100%, Waterproof.

8. Application Examples: Musical Fountain, Dancing Fountain, Air Blast Water Fountain, etc.



Main Dimension of Fountain Stainless Steel Solenoid Valve:

Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC 0




Model
A
B
C
D
BDF215
75
48
125
13.5
BDF220
83
60
145
17.5
BDF225
100
72
150
22
BDF232
130
97
155
28
BDF240
130
97
155
28
BDF250
155
122
160
32



Technical Data of Fountain Stainless Steel Solenoid Valve:

BDF Series
BDF215
BDF220
BDF225
BDF232
BDF240
BDF250
Orifice Size
15
20
25
32
40
50
Port Size
1/2''
3/4''
1''
1 1/4''
1 1/2''
2''
Connection Type
Threaded (G, NPT), Flanged
Medium
Water
Action
Diaphragm Pilot Operated
Function
2 Way Normally Closed
Body Material
Stainless Steel
Seal Material
NBR, FKM, EPDM
Pressure
Range
0.05 to 2.5MPa
Temp. Range
NBR: -10 to +80℃
EPDM: -30 to +120℃
FKM: -30 to +150℃
Coil Voltages
AC: 24V, 120V, 240V (60Hz), 110V, 220V (50Hz)
DC: 12V, 24V
Coil Power
26VA, 13W
Protection Class
IP68 Waterproof


Brando Factory Production of Solenoid Valves:

Air Blast Water Fountain Stainless Steel Solenoid Valve IP68 1 1/4'' 1 1/2'' 24VDC 220VAC 1



As a solenoid valve supplier, BRANDO supplys general purpose solenoid valve for general mediums control. Such as water, air, gas, oil. Offering the cost-effective solution for your projects. Available in brass, stainless steel and PVC material for your projects.


● Size Range: 1/4" to 2" (1/4", 3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4")
● Voltage: 12 Volt DC, 24 Volt DC, 24 Volt AC, 110 Volt AC, 220 Volt AC
● Pressure: 0-10 bar / 0.3-16 bar
● Temperature: -10℃~180℃
● Material: Brass, Stainless Steel and PVC
● Structure: Direct Acting / Diaphragm / Pilot Operated
● Function: Normally Closed / Normally Open
● Connection Type: Threaded, Flanged, Tri Clamp
● Tolerance: ±10%
