Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve

Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve

    • Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve
    • Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve
    • Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve
    • Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve
    • Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve
  • Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: BAPC210030051

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Packaging Details: inner boxes,cartons,pallets
    Delivery Time: 7 working days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100000pcs per month
    Contact Now
    Detailed Product Description
    Ref Number: CP 1/4 Guide Tube Outer Diameter: 10.0mm
    Installation Height For Coil Assembling: 28.7mm Plunger Seal For Orifice Diameter: 5.6mm
    Guide Tube Material: Stainless Steel Seal Material: NBR
    Mounting Type: Thread Voltage: AC, DC All Available
    Application: VNP 200/300/400/500/600/700 Series Pulse Valve

    Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve

    VNP / VEM series electromagnetic pulse valve is used for the pressure cleaning system of pulse cleaning bag type dust collector. When the electromagnetic pulse valve is activated by the controller, the compressed gas in the air bag is sprayed into the filter bag through the pulse valve to clean the dust of the pollutants outside the filter bag, so as to clean the filter bag, reduce the resistance of the dust filter, and extend the filter material work The effect of longevity.
    Its unique design ensures that the valve has the characteristics of quick opening, high distortion and easy installation. The valve is made of aluminum alloy die-casting, plus black anti-corrosion treatment, suitable for applications in harsh industrial systems. All bolts and screws are made of stainless steel.



    Ref Number: CP 1/4
    Guide Tube Outer Diameter:10.0mm
    Installation Height for Coil Assembling:28.7mm
    Plunger Seal for Orifice Diameter:5.6mm
    Guide Tube Material:Stainless Steel
    Seal Material:
    NBRMounting Type:
    ThreadVoltage:AC, DC All Available
    Position and Way:2/2 Way
    Non-working Status:Normally Close
    Application:VNP 200/300/400/500/600/700 Series Pulse Valve



    Youtube Video About CP 1/4 Pilot Armature For Mecair Pulse Valve:





    Dimension:

    Mecair Type Solenoid Stem CP1/4 Plunger Tube Assembly For VNP 200/300/400/500/600/700 Diaphragm Pulse Valve

    Specification:

    Model Number
    BAPC210030051
    Guide Tube Outer Diameter
    10.0mm
    Installation Height for Coil Assembling
    28.7mm
    Plunger Seal for Orifice Diameter
    5.6mm
    Guide Tube Material
    Stainless Steel
    Seal Material
    NBR, HNBR, FKM, EPDM, Silicone, all available
    Connection Type
    Thread
    Voltage
    All range of AC and DC available
    Position and Way
    2/2 Way
    Non-working Status
    Normally Closed
    Application Examples
    VNP 200/300/400/500/600/700 Series Pulse Valves
    Customized Service
    Provided, welcome show us sample or drawing





    Product Features:
    1. Fixed core and movable core (plunger):
    Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.
    2. Guide tube (plunger tube):
    Options of brass and stainless steel, grade of H62 or SUS304;
    Wall thickness from range of 0.25~2.5mm, others could be customized;
    Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.
    3. Spring:
    Rustproof SUS304 stainless steel, with good performance of restore.
    4. Seals:
    Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.
    5 Shading ring:
    Cooper and silver material available.
    6. Washer and retaining nut provided if has demands.



    Focus on your demands, Offer you best solution:
    √ Contact us if some points you have doubt
    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for
    √ Contact us if you are doing designing
    Welcome to your any question and inquiry!
