SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves

SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves

    • SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves
    • SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves
    • SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves
    • SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves
  • SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE, ISO
    Model Number: SCG353A043

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: negotiation
    Packaging Details: Plastic Bag, box, carton, pallet
    Delivery Time: 3 DAYS
    Payment Terms: T/T, Western Union
    Supply Ability: 800PCS PER DAY
    Contact Now
    Detailed Product Description
    Model Number: SCG353A043 Diaphragm: TPE White Color
    Size: 3/4" Voltage: DC24V AC110V AC220V
    Application: For Dust Collector Cleaning System Weight: 0.70 Kgs
    Temperature: -5℃ To +55℃

    SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves



    The principle of pulse valve SCG353A043 working:

    Diaphragm pulse valves are the most important components of a baghouse pulse jet cleaning system.

    On a pulse jet baghouse pulse valves (also called diaphragm valves) control the release of air pulses during the cleaning cycle. When the baghouse control board or timer board initiates a cleaning cycle it sends an electrical signal to the solenoids, when then activate the pulse valve.

    Inside the pulse valve, a rubber diaphragm opens and closes to release the compressed air stored in the air header tank. The air then passes through the valve into the blow pipes above the filters and then is directed down into the filters to clean them.



    Illustration of Pulse Valve SCG353A043 working:

    SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves



    Specification of Pulse Valve SCG353A043:

    SCG353A043 Operation Pressure 0.3~0.8Mpa
    SCG353A043 Ambient temperature -5~55℃
    SCG353A043 Relative humidity <85%
    SCG353A043 Fluid Clear Air
    SCG353A043 Voltage AC110V AC220V DC24V
    SCG353A043 Electric current 0.46A, 0.23A, 0.8A +-10%
    SCG353A043 Diaphragm working life More than 1 million times
    SCG353A043 Diameter 20mm
    SCG353A043 Threaded Pipe Size G3/4"



    Dimensions of Baghouse Pulse Valve SCG353A043:

    SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves

    SCG353A043 - G3/4, Orifice Size 20mm, Threaded, Aluminium Body, NBR Seal, Series 353 Dust Collector Pulse Valves



    Construction of Pulse Valve SCG353A043:

    SCG353A043 Body Material Aluminium
    SCG353A043 Core Tube Material SS304
    SCG353A043 Core 430FR
    SCG353A043 Coil Copper
    SCG353A043 Sealing and Disc NBR
    SCG353A043 Diaphragm TPE or FPM
    SCG353A043 Shading Ring Copper
    SCG353A043 Spring SS304
    SCG353A043 Connector DIN43650A
    SCG353A043 Electrical Safety IEC335
