Name: G1/2" NC Nitrile Diaphragm Stainless Steel 2S160-15 SUW-15 Uni-D Type Solenoid Valve AC220V
Brand: Brando
SKU: SUW-15
Price: 3 USD
Availability: InStock
Rating: 4.7 (154 reviews)

Home Products Stainless Steel Solenoid Valve

G1/2" NC Nitrile Diaphragm Stainless Steel 2S160-15 SUW-15 Uni-D Type Solenoid Valve AC220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	SUW-15

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$3 to $10 per set
Packaging Details:	Internal boxes, Carton, pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	250000 sets per month

Contact Now

Detailed Product Description

Product Name:	SUW-15 UNI-D Type Solenoid Valve	Port Size:	1/2'' (G, NPT, BSP, PT)
Orifice Size:	15mm	Function:	2-Way Normally Closed
Operation:	Semi-direct	Diaphragm Material:	NBR/Nitrile/Buna (Common), VITON(Available)
Voltages:	DC24V, AC110V, AC220V	Connection Type:	Female Threaded
Medium:	Water, Air, Light Oil, Gas, Vacuum	Temperature Range:	-5 To +80℃
High Light:	Stainless Steel 304 Solenoid Valve , 2 Way SS Solenoid Valve , Water Treatment Solenoid Valve

G1/2'' NC Nitrile Diaphragm Stainless Steel 2S160-15 SUW-15 Uni-d Type Solenoid Valve AC220V

PRODUCT DESCRIPTION:
1. SUW series is direct, multiplex, connected diaphragm, conductive and normally closed (NC) 2/2 way solenoid valve;

2. Orifice size from 2.5 to 50mm, and port size from 1/8'' to 2'';

3. The pipe connection could be G, NPT, BSP, PT;
4. Able to be operated directly under low pressure;
5. Availability of fluid type:water, air, light oil, gas, vacuum;
6. Acceptable for customization Viton (130℃) , Silicone (130℃) and EPDM (130℃) for plug and diaphragm.

Youtube video of 1/2'' 2S160-15 SUW-15 UNID Type Solenoid Diaphragm Valve:

Main dimension of G1/2'' 2S160-15 Semi-direct Diaphragm Operated Solenoid Valve:

Technical parameters of SUS & SUW NBR Diaphragm Unid Type Solenoid Valve:

2S Series	Uni-D Type	PIPE SIZE	CV	ORIFICE	FLUID TEMP. (°C)	Operating Pressure kgf/ cm2 (bar)
2S Series	Uni-D Type	PIPE SIZE	CV	ORIFICE	FLUID TEMP. (°C)	Water	Air	Light oil
2S025-06	SUS-6	1/8''	0.23	2.5mm	-5°C- +80°C	0-7	0-7	0-7
2S025-08	SUS-8	1/4''	0.23	2.5mm	-5°C- +80°C	0-7	0-7	0-7
2S040-10	SUS-10	3/8''	0.58	4mm	-5°C- +80°C	0-7	0-7	0-7
2S160-10	SUW-10	3/8"	4.5	15mm	-5°C- +80°C	0-5	0-7	0-5
2S160-15	SUW-15	1/2''	4.5	15mm	-5°C - +80°C	0-5	0-7	0-5
2S200-20	SUW-20	3/4"	8.6	20mm	-5°C- +80°C	0-5	0-7	0-5
2S250-25	SUW-25	1"	12	25mm	-5°C- +80°C	0-5	0-7	0-5
2S350-35	SUW-35	1-1/4"	24	35mm	-5°C- +80°C	0-5	0-7	0-5
2S400-40	SUW-40	1-1/2"	28	40mm	-5°C - +80°C	0-5	0-7	0-5
2S500-50	SUW-50	2"	48	50mm	-5°C - +80°C	0-5	0-7	0-5

Details display of SUW-15 Nitrile Diaphragm Operated Electromagnetic Valve:

Application examples of 2S, SUS & SUW Seies Stainless Steel Solenoid Valve:

CAUTIONS:
1. Before pipelining, the pipe line must be very clean without any contaminants or any other things not ought to be existed.
2. To prolong the life time of the product, Y-line filter should be installed in the front end of solenoid valve.
3. AC voltage tolerance:±10%；DC voltage tolerance:±1%
4. It should be installed horizontally；vertical installation is not advisable.

Not Suitalbe For Fluid As Below:
1. Liquid status when it is high temperature；solid status when it is cool.
2. Corrosive fluid
3. Viscosity over 20cst
