Sporlan Type Hot Gas Bypass Valve ADRIE-1-1/4 ADRSE-2 ADRPE-3 ADRHE-6

Large Image : Sporlan Type Hot Gas Bypass Valve ADRIE-1-1/4 ADRSE-2 ADRPE-3 ADRHE-6

Product Details:

Place of Origin:	China, Ningbo
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	ADRIE-1-1/4, ADRSE-2, ADRPE-3, ADRHE-6

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Hot Gas Bypass Valve	Connection Size:	3/8'', 1/2'', 5/8'', 7/8'', 1 1/8''
Connection Type:	Solder	External Equalizer Connection:	1/4''
Equalization:	Externally Equalized	Refrigerant:	R134a, R401A, R22, R402A, R404A, R407C, R507
Body Style:	I, S, P Or H	Adjustment Range:	0/30, 0/80, 55/70, Etc
Highlight:	Sporlan Hot Gas Bypass Valve , Discharge Hot Gas Bypass Valve , Sporlan ADR

Sporlan Type Hot Gas Bypass Valve ADRIE-1-1/4 ADRSE-2 ADRPE-3 ADRHE-6

The hot gas bypass valve is a valve that automatically regulates the cooling temperature in the dryer exchanger based on the refrigerant pressure. The pressure measured after the heat exchanger directly correlates to the temperature in the system. A low pressure means there will be a low temperature.

Technical Data of ADR Hot Gas Bypass Valve:

Valve Type		Connection Size	Dimension (inch)					Adjustment Range	Standard Setting
Internally Equalized	Externally Equalized		A	B	C	D	E
Adjustable Models
ADRI-1-1/4	ADRIE-1-1/4	3/8'' ODF	4.86 Max	1.79	1.38	1.69	1.33	0 to 5.5 bar	2.5 bar
ADRS-2	ADRSE-2	3/8'' ODF	6.44	2.5	1.94	1.44
		1/2'' ODF				1.37
		5/8'' ODF				1.50
		3/8'' SAE				1.69	1.75
		1/2'' SAE				1.87	1.94
		5/8'' SAE				2.06	2.12
ADRP-3	ADRPE-3	1/2'' ODF	6.94	2.81	2.06	1.69	1.62
		5/8'' ODF				1.81	1.75
		1/2'' SAE				2.06
		5/8'' SAE				2.19
Not Available	ADRHE-6	5/8'' ODF	7.06	2.88	1.88	4.62
		7/8'' ODF
		1 1/8'' ODF
Adjustable "Remote Bulb" Model
Not Available	DRHE-6	5/8'' ODF	4.88	2.88	1.88	4.62		/	/
		7/8'' ODF						/	/
		1 1/8'' ODF						/	/

More Refrigeration Parts for you to choose:


Refrigeration Solenoid Valve	Reversing Valve	Refrigeration Ball Valve

Crankcase Pressure Regulator	Expansion Valve	Sight Glass

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
