Pneumatic Actuator Valve

Pneumatic Actuator Valve

  • Pneumatic Actuator Valve
Pneumatic Actuator Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Q611
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner boxes, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 50000 pcs per month
Contact Now
Detailed Product Description
Structure: Ball, Butterfly Power: Pneumatic
Pipe Connection: Thread, Flange, Tri Clamp, Wafer, Union Body Material: Cast Iron, Cast Steel, SS304, SS316, UPVC, CPVC
Seal Material: Rubber, PTFE, TFM, Stainless Steel Working Medium: Neutral Gas, Air
Port Size: DN10 To DN200 Air Pressure: 0.4 To 0.8 MPa
High Light:

Pneumatic Actuator Ball Valve


Pneumatic Actuator Butterfly Valve


Pneumatic Actuator Control Valve

Pneumatic Actuator Valve


Pneumatic actuated valves used compressed air flowing into and exhausting from an actuator to open and close the valve. The type of pneumatic actuator required depends on the actuator valve. Valves requiring linear motion (gate, globe or diaphragm valves) typically require a pneumatic diaphragm actuator. Quarter turn valves (ball and butterfly valves) typically require either a rack-and-pinion actuator or a scotch yoke actuator. We'll discuss the two types on quarter-turn air actuators in greater detail.


Double Acting

Double acting actuators use compressed gas driving a piston to both open and close the valve. These actuators have two ports to pass and exhaust the gas. Compressed gas is fed through the first port, causing the actuator to close the valve, and then exhausted out the second port. To return to the original position the supply and exhaust functions are reversed.


Spring Return

Spring return actuators typically have a single port to both pass and exhaust the compressed gas. Unlike double acting actuators, spring return actuators are driven in a single direction and, when the gas is exhausted, use springs to return to the original position. The valve can be installed to return to either the closed or open position; the more common mode is normally closed.


Technical Data of Pneumatic Actuator Valve:

Pneumatic Actuator Valve
Electric Actuator Valve
Air Pressure: 0.4 to 0.8 MPa
Electric Actuator Power:
380VAC, 220VAC, 110VAC (50/60Hz), 24VDC
Electric Actuator Input: 4-20mA. DC
Control Medium: Neutral Gas, Air
Ambient Temperature: -20 to +60℃
Medium Temperature: -20 to +180℃
UPVC Ball Valve: -10 to +45℃
CPVC Ball Valve: -15 to +90℃
Normal Seal's Working Temperature: PTFE (-20 to +180℃), TFM (-30 to +230℃)
Manufacturing Standard: GB, ISO, ANSI, BS, DIN


Pneumatic Ball Valves for you to choose:

Pneumatic Actuator Valve 0 Pneumatic Actuator Valve 1 Pneumatic Actuator Valve 2 Pneumatic Actuator Valve 3
Pneumatic Actuator Valve 4 Pneumatic Actuator Valve 5 Pneumatic Actuator Valve 6 Pneumatic Actuator Valve 7


Pneumatic Butterfly Valves for you to choose:

Pneumatic Actuator Valve 8 Pneumatic Actuator Valve 9 Pneumatic Actuator Valve 10 Pneumatic Actuator Valve 11


Accessories for Pneumatic Actuator Valves:

Pneumatic Actuator Valve 12 Pneumatic Actuator Valve 13 Pneumatic Actuator Valve 14
Pneumatic Actuator Limit Switch Namur Solenoid Valve
