Yuken Type Hydraulic Solenoid Valve Coil

Yuken Type Hydraulic Solenoid Valve Coil

  • Yuken Type Hydraulic Solenoid Valve Coil
Yuken Type Hydraulic Solenoid Valve Coil
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: Hydraulic
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 set per month
Contact Now
Detailed Product Description
Product Name: Hydraulic Solenoid Valve Coil Connection Type: DIN 43650A, 2 Pins (Plug In Type)
Voltages: 12VDC, 24VDC, 110VAC, 220VAC Coil No: D12, D24, D100, A100, A120, A200, A240, R100, R200, RQ100
Power: 28W, 30W, 35W, 42W Insulation Class: H, F
Protection Class: IP65, IP67 Replacement Brand Coil: Yuken
High Light:

Yuken Hydraulic Solenoid Coil

,

Hydraulic Valve Yuken Coil

,

Yuken Solenoid Valve Coil

Eaton Vickers Type Hydraulic Solenoid Valve Coil



Specification:
1. Voltage: 12VDC, 24VDC, 110VAC, 120VAC, 220VAC, 240VAC
2. Application: For Yuken hydraulic solenoid valve
3. Coil No: D12, D24, D100, A100, A120, A200, A240, R100, R200, RQ100
4. Connector type: DIN 43650A, 2 Pins (Plug In Type)

5. Valve Type: Yuken directional control valve, DSG-01 series, DSG-03 series
6. Valve Sizes: 6, 10.



Yuken solenoid coil, also known as Yuken valve coil, or Yuken coil for directional valves. Yuken solenoid coil is the main part of Yuken hydraulic solenoids. The hydraulic solenoid is the actuator of Yuken DSG directional valves. A complete hydraulic solenoid is consist of a solenoid coil and a solenoid tube assembly.



Solenoid coil is a hollow bobbin winding with a bunch of copper wires. When the solenoid coil has been electrified, the copper wires will create a magnetic field, and the magnetic field makes the plunger in solenoid tube move and triggers the operation of the directional valves.



Features:

1. The Yuken solenoid coil is encapsulated with high quality glass-filled nylon, which has better intensity, rigidity, thermostability, etc.
2. The solenoid bobbin of Yuken solenoid coil uses the quality material with 30% glass-filled thermoplastic polyester, which can enhance the thermostability of the solenoid bobbins.
3. Multiple choices of solenoid copper wires, Kaidi provides solenoid coils with class F, class H, class N copper wires, and the IP grade can reach IP65 and IP67.



Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture Dimension
Model
BB23660411
Yuken Type Hydraulic Solenoid Valve Coil 0 Yuken Type Hydraulic Solenoid Valve Coil 1
Voltage
12VDC, 24VDC, 110VAC, 220VAC
Power
42W
Connector Type
DIN43650A
Insulation Class
F
Protection Class
IP65



Picture Dimension
Model
BB23660407
Yuken Type Hydraulic Solenoid Valve Coil 2 Yuken Type Hydraulic Solenoid Valve Coil 3
Voltage
12VDC, 24VDC, 110VAC, 220VAC
Power
30W
Connector Type
DIN 43650A
Insulation Class
F
Protection Class
IP65





Picture Dimension
Model
BB20151537
Yuken Type Hydraulic Solenoid Valve Coil 4 Yuken Type Hydraulic Solenoid Valve Coil 5
Voltage
12VDC, 24VDC, 110VAC, 220VAC
Power
30W
Connector Type
2 Pins (Plug In Type)
Insulation Class
F
Protection Class
IP65



Picture Dimension
Model
BB26149508
Yuken Type Hydraulic Solenoid Valve Coil 6 Yuken Type Hydraulic Solenoid Valve Coil 7
Voltage
110VAC, 220VAC
Power
35W
Connector Type
2 Pins (Plug In Type)
Insulation Class
H
Protection Class
IP67



Brando Factory Production of Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil 8



Other hydraulic solenoid valve coil fo you to choose:



Vickers Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil 9Yuken Type Hydraulic Solenoid Valve Coil 10Yuken Type Hydraulic Solenoid Valve Coil 11Yuken Type Hydraulic Solenoid Valve Coil 12



Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil 13Yuken Type Hydraulic Solenoid Valve Coil 14Yuken Type Hydraulic Solenoid Valve Coil 15Yuken Type Hydraulic Solenoid Valve Coil 16



Advantages of our hydraulic solenoid coil as follows:

1. A variety of integrated connections and wires ideas available.


2. The advanced design of one-piece and shell encapsulated, and hydraulic solenoid coil meets the most stringent environmental requirements for mobile and industrial applications.


3. IP69K Environmental Protection: IP69K can prevent dash and high-pressure spray entering the solenoid coil. IP69K test is focused on the rating protection against high-pressure spray, high-temperature liquid and close nozzle distance from the enclosure surface. IP69K is standard on coils with MetriPac or Deutsch, integrated connectors.


4. Our hydraulic solenoid coil can replace all current Eaton Vickers coils used on D Frame and Shell type coils. Compact coil applies for most 8, 10, 12, 16 and 20 series valves.


5. No additional water/weather proofing is needed.


6. The design of steel shell encapsulated provides protection against physical and environmental damage.
