RO SV Solenoid Valve Plunger

RO SV Solenoid Valve Plunger

RO SV solenoid valves for water purifiers (reverse osmosis systems) are of 2/2 way (1 inlet, 1 outlet of the open/closed type), ideal for water ON/OFF control. RO SV solenoid valves have a compact design. The solenoid valve plunger rests directly over the flow path or orifice and controls the on/off function of the solenoid valve. As it does not use a membrane, the flow is restricted according to the orifice size. Normally orifice size is between 1mm to 5mm. As the type of valves is direct acting, they do not depend on system pressure differences to function. This makes them ideal for the low flow, small, medium and high-pressure systems up to 120 bar. Port sizes range from 1/8'' to 3/8''. 2 way valves are closed when de-energized and open when energized.

Dimension & Data of RO SV Solenoid Valve Plunger:

Picture	Dimension	Model	BAPC211030002
		Function	2 Way, Normally Closed
		Tube Material	Stainless Steel
		Seal Material	NBR, FKM, other all available
		Seat Type	Flange
		Application Example	RO Solenoid Valve

Picture	Dimension	Model	BAPC211030036
		Function	2 Way, Normally Closed
		Tube Material	Stainless Steel
		Seal Material	NBR, FKM, other all available
		Seat Type	Flange
		Application Example	RO Solenoid Valve

Brando Solenoid Valve Plunger Production Video:

More RO Solenoid Valves For you to choose:

RO solenoid valves are used to control the supply of feed water to water purifier reverse osmosis systems. They have an ON/OFF function. They are offered in various styles and suitable for many plumbing scenarios.

More RO Quick Fittings For you to choose:

Introduction of ro water purifier system:

Water purifier systems can help to eliminate contaminants that can make you sick or affect the taste or feel of your water supply. In a Reverse Osmosis (RO) water purifying system, reverse osmosis is utilized to dissolve inorganic solids (such as salts) and removes them from a solution (such as water). This is achieved by using the household water pressure to push tap water through a semi permeable membrane. The membrane (which is about as thick as cellophane) allows only the water to pass through, not the impurities or contaminates. These impurities and contaminates are flushed down the drain. These systems use a lot of water, but they do remove all microbes that cause disease and a lot of chemicals. This is an extremely effective system for purifying water.
