VF3130 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24VDC 220VAC

VF3130 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24VDC 220VAC

  • VF3130 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24VDC 220VAC
VF3130 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24VDC 220VAC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: VF3130
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: $3 to $ 5 per pc
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Valve Type: 5 Way 2 Position Port Size: In=Out=1/4'', Exhaust=1/8''
Pressure Range: 0.15 To 0.8MPa Max Pressure Resistance: 1.2 MPa
Body Material: Aluminum Alloy Wiring Form: Lead Wire Or DIN43650 Connector
Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

SMC Pneumatic Solenoid Valve

,

Pneumatic Solenoid Valve 24VDC

,

SMC VF3130

VF3130 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24VDC 220VAC



Pneumatic valve is where air or an inert gas is the pneumatic drive force. These type of pneumatic valves control or manage the source air within an automated system. While frequently referred to as pneumatic valves, they can be actuated (operated) by manually, by pneumatic actuation (Air Pilot Valve), by solenoid actuation (Pneumatic Solenoid Valve), or by motorized actuation. Ultimately, they all serve the same purpose: they modulate or control the source air for an automated system.



Technial Data of VF & VZ Series Pneumatic Solenoid Valves:

Model
VF3130
VF33(4/5)30
VF5120
VF53(4/5)50
VZ5120
VZ53(4/5)50
VF3230
VF5220
VZ5220
Valve Type
5/2 way
5/3 way
5/2 way
5/3 way
5/2 way
5/3 way
Orifice Size
16mm²
(Cv=0.89)
12mm²
(Cv=0.67)
25mm²
(Cv=1.4)
18mm²
(Cv=1)
12mm²
(Cv=0.67)
9mm² (Cv=0.50)
Fluid
Air (to be filtered by 40 μm filter element)
Operating Pressure
0.15 to 0.8 MPa
Proof Pressure
1.2 MPa
Body
Material
Aluminum Alloy
Max
Frequency
5 cycle / sec
Voltage
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Wire Form
Lead Wire or DIN43650 Connector


Dimension of VF3130 Pneumatic Solenoid Valve:

VF3130 SMC Type Pneumatic Air Solenoid Valve 5/2 Way 24VDC 220VAC 0
