Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion

Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion

  • Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion
Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: DNC
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 work days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Series: Piston Rod Cylinder Bore Size (mm): 32, 40, 50, 63, 80, 100, 125
Standard Stroke (mm): 25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 Acting Type: Double Acting
Operating Pressure Range: 0.15 To 1.0 MPa Proof Pressure: 1.5 MPa
High Light:

Festo Cylinder DNC Series

,

Pneumatic Cylinder Adjustable Cushion

,

Festo DNC-50-50-PPV-A

Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion



A pneumatic cylinder is a type of appliance that makes the use of power that is generated from compacted gas in order to form a force in interchanging linear motion. A pneumatic cylinder may also be referred to as an air cylinder, as the term pneuma, means air. Very similar to hydraulic cylinders, a force is applied into the piston, which pushes it to the desired direction. The piston that is part of a pneumatic cylinder is a disc or a cylinder. The force that is created is transported by the piston rod to the object that requires moving. A minority of engineers prefer this device due to its cleanness, quietness, and minimum space for storing fluids.


Specifications of DNC Series Pneumatic Cylinder:

Bore Size (mm) 32 40 50 63 80 100 125
Acting Type Double Acting
Fluid Air (to be filtered by 40μm filter element)
Operating  Pressure Range 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi)
Proof Pressure 1.5 MPa (15 bar) (215 psi)
Temprature (℃) -20 to +80
Speed Range (mm/s) 30 to 800
Cushion Type Variable cushion
Port Size 1/8'' 1/4'' 3/8'' 1/2''


Stroke of DNC Series Pneumatic Cylinder:

Bore Size (mm) Standard Stroke (mm) Max. Std Stroke Max. Stroke
32

25, 50, 75, 80, 100, 125, 150, 160, 175,

200, 250, 300, 350, 400, 450, 500

1000 1800
40

25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250,

300, 350, 400, 450, 500, 600, 700, 800

1200 1800
50

25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300,

350, 400, 450, 500, 600, 700, 800, 900, 1000

1200 1800
63 1500 1800
80 1500 1800
100 1500 1800
125 1500 1800


Ordering Code of DNC Series Pneumatic Cylinder:


Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion 0
