Brass Fast Twist Pneumatic Fitting Plug-In Straight 1/8'' 1/4'' 3/8'' 1/2''

Brass Fast Twist Pneumatic Fitting Plug-In Straight 1/8'' 1/4'' 3/8'' 1/2''

  • Brass Fast Twist Pneumatic Fitting Plug-In Straight 1/8'' 1/4'' 3/8'' 1/2''
Brass Fast Twist Pneumatic Fitting Plug-In Straight 1/8'' 1/4'' 3/8'' 1/2''
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE, ISO
Model Number: BCSM-G
Payment & Shipping Terms:
Minimum Order Quantity: 5 pcs
Price: Negotiation
Packaging Details: PVC bag, then inner box, then carton, then pallet
Delivery Time: 1 week after payment
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 10000000pcs per month
Contact Now
Detailed Product Description
Product Name: Pneumatic Hose Fittings Type: Plug-In Straight
Tube OD (Inch): 1/8", 1/4", 3/8", 1/2" Tube OD (Mertric): 4mm, 6mm, 8mm, 10mm, 12mm
Material: Brass Working Pressure Range: 0 To 0.8MPa
Working Temperature: 0 To +60℃ Connection: Fast Twist
High Light:

Fast Twist Pneumatic Fitting

,

Quick Twist Pneumatic Fitting

,

Fast Twist Pneumatic Hose Fitting

Brass Fast Twist Pneumatic Fitting Plug-In Straight 1/8'' 1/4'' 3/8'' 1/2''



CNC Machining & Turning Pneumatic Fittings & Air Fittings in an array variety of sizes, body styles, materials (plain brass, nickel plated brass, plastic, stainless steel and more), thread types depending on customer specifications and requirements can be manufactured here to fit in for a number of mechanical industrial applications and processes!



Advantages of Our CNC Machining Services for Pneumatic Fittings:

Wide Range: Vast number of types of pneumatic fittings in materials, shapes, functions, sizes
Top Grade: High quality materials, high-precision tolerances, professional team
Excellent Performance: Great pressure-holding capacity, corrosion resistance, tube compatibility
Best Prices: Competitive pneumatic fitting prices, cost-effective customized order
OEM/ODM: Professional CNC turning service for complex customized pneumatic fittings
Awesome Services: One-stop service from quotation, design, production, quality inspection, packaging, delivery, to after-sales



Technical data of Pneumatic Hose Fittings:

Material
Plastic / Brass
Threaded Connection
BSP
BSPP
Metric Thread
NPT
Working Pressure
0 to 0.8MPa
Connecting Tube
PA
PU
Connecting Diameter Tube
3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 16mm (Outer Diameter)
Medium
Compressed Air
Working Temperature
~60℃



Specifications of Plug-In Straight Fast Twist Pneumatic Hose Fittings:

                                                       Brass Fast Twist Pneumatic Fitting Plug-In Straight 1/8'' 1/4'' 3/8'' 1/2'' 0

Model No
D
L1
L
S
S1
G
BCSM-2.5-G
4
20
36
10
8
4
21
37
6
22
38
8
23
39
10
BCSM-4-G
6
20
37
12
10
4
21
38
6
22
39
8
23
20
10
BCSM-6-G
8
20
36
13
13
4
21
37
6
22
38
8
23
39
10
23
39
12
BCSM-8-G
10
20
41
15
15
4
21
42
6
22
43
8
23
44
10
23
45
12
BCSM-10-G
12
20
42
17
17
4
21
43
6
22
44
8
23
45
10
23
46
12



Product Video of BRANDO Fast Twist Pneumatic Hose Fittings:


List of All Quick Twist Brass Pneumatic Hose Fittings:

all list



Choosing the Right Fittings for Your Pneumatic System:



Fittings help control the force and directional flow of compressed gas or air used in pneumatic systems. One of the first considerations in choosing a connector is the type of vessel that you will be connecting to such as the flexibility of the hose or tube, as well as the inner diameter (ID) and outer diameter (OD) of the vessel to ensure an adequate seal and secure connection. Fitting material choice for your pneumatic connector is also important, including gas compatibility or resistance to heat or corrosion.

Other considerations in choosing the right pneumatic system connector include:
1. Type of connection and the function it performs
2. Operational pressure of the pneumatic system
3. Operating temperature range
4. P.S.I. requirements for your application
5. Amount of vibration produced by the pneumatic system
6. Thread type of the receiving fitting



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing


Welcome to your any question and inquiry!
