4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve

4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve

  • 4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve
  • 4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve
  • 4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve
4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V130C-06
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Port Size: In=Out=1/8'' Valve Type: Double Solenoid 5 Port 3 Position
Voltage: 220VAC 110VAC 24VDC 12VDC Connector: Terminal & Grommet
Working Pressure: 0.15 To 0.8MPa(21-114psi) Temperature: -20 To +70℃
Max. Frequency: 5 Cycle/sec Body Material: Aluminum Alloy
Fluid: Air (to Be Filtered By 40 μm Filter Element) Application: Automation
High Light:

4V130C-06 Pneumatic Solenoid Valve

,

5/3 Way Pneumatic Solenoid Valve

,

4v130c-06 Pneumatic Air Valve

4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve



5/3-way pneumatic solenoid valves
A 5/3-way valve has five ports and three states. They have two solenoids that each can control a valve state. If no solenoid is energized, the valve returns to the central state. Therefore, the valve is mono-stable. The central state can have different functions, such as closing off all ports. An example of an application is a double acting cylinder that has to be locked at intermediate positions along the stroke.





Technical Data:

Model
4V110-06
4V120-06
4V130C-06
4V130E-06
4V130P-06
4V110-08
4V120-08
4V130C-08
4V130E-08
4V130P-08
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=1/8''
In=Out=1/4''
Orifice Size
5.5 mm2 (Cv=0.31)
5.0 mm2 (Cv=0.28)
12.00 mm2 (Cv=0.67)
9.00 mm2 (Cv=0.50)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa (21~114psi)
Proof Pressure
1.5MPa (215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec






Dimension Diagram:

4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve 0

4V130(Grommet)

4V130C-06 1/8'' 5/3 Way Terminal Grommet Pmeumatic Solenoid Valve 1

4V130(Terminal)
