4A420-15 Airtac Type 5/2 Way Double Air Piloted Pneumatic Valve

4A420-15 Airtac Type 5/2 Way Double Air Piloted Pneumatic Valve

  • 4A420-15 Airtac Type 5/2 Way Double Air Piloted Pneumatic Valve
4A420-15 Airtac Type 5/2 Way Double Air Piloted Pneumatic Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4A420-15
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Valve Type: 5 Way 2 Position Port Size: In=Out=Exhaust=1/2''
Pressure Range: 0.15 To 0.8 MPa Max Pressure Resistance: 1.5 MPa
Body Material: Aluminum Alloy Max Frequency: 3 Cycle/ Second
Acting: External Control
High Light:

Airtac Pilot Valve

,

Double Air Piloted Valve

,

Airtac 4A420-15

4A420-15 Airtac Type 5/2 Way Double Air Piloted Pneumatic Valve



Air Pilot Valve Features:


1. Good tightness and sensitive reaction;
2. Three position with three kinds of central function for your choice;
3. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life.
4. Integrate with the manifold to save installation space.
5. Single valve or multiple manifold mounted valve applications
6. Finally a compact design with maximum flow.




Technical Data of 4A400 Series Pneumatic Air Pilot Valve:

Model
4A410-15
4A420-15
4A430C-15
4A430E-15
4A430P-15
Fluid
Air (to be filtered by 40μm filter element)
Acting
exterior control
Port Size
in=out=exhaust=1/2''
Orifice Size
4A410-15, 4A420-15: 48.0mm² (Cv=2.82)
4A430C-15: 40.0mm² (Cv=2.35)
Valve Type
5 way 2 position
5 way 3 position
Operating Pressure
0.15 to 0.8 MPa (21 to 114 psi)
Proof Pressure
1.2MPa (175psi)
Temperature
-20 to 70℃
Body Material
Aluminum Alloy
Max Frequency
3 cycle/sec


Dimension of 4A420-15 Pneumatic Air Pilot Valve:

4A420-15 Airtac Type 5/2 Way Double Air Piloted Pneumatic Valve 0
