4TB-20 4-Way Reversing Valve for Compatible Heat Pump and HVAC Systems

4TB-20 4-Way Reversing Valve for Compatible Heat Pump and HVAC Systems

  • 4TB-20 4-Way Reversing Valve for Compatible Heat Pump and HVAC Systems
4TB-20 4-Way Reversing Valve for Compatible Heat Pump and HVAC Systems
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: None
Model Number: 4TB-20
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: Negotiation
Payment Terms: T/T,Western Union,
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: 4 Way Reversing Valve D Port Size: 12.8mm (1/2'')
E.S.C Port Size: 19.2mm (3/4'') Power: 4 To 8HP
Applicable Refrigerant: R22, R407C, R410A, Etc Application: Heat Pump, Air Conditioning, Etc
Voltage: 24VDC, 24VAC, 110VAC, 220VAC
Highlight:

4TB-20 4 way reversing valve

,

4TB-20 reversing valve

,

Heat pump reversing valve

4TB-20 4-Way Reversing Valve for Compatible Heat Pump and HVAC Systems


The 4TB-20 4-way reversing valve is designed for use in compatible heat pump and HVAC applications. A 4-way reversing valve controls the direction of refrigerant flow, allowing a heat pump system to switch between heating and cooling modes.


When choosing a 4TB-20 reversing valve, check the model number, connection dimensions, operating pressure, coil specifications, and compatibility with your existing equipment. Always refer to the manufacturer's technical datasheet to verify product specifications and application requirements.

Contact us for more information about the 4TB-20 4-way reversing valve, technical details, and availability.


Technical Data:

Dimension - logo
Model No
Orifice Size
(mm)
Port Size
(mm)
Operating Pressure Difference (MPa)
Internal Leakage (ml/min)
P=1MPa at 70℃
Power
(HP)
D
E.S.C
Min
Max
4TB-4U
8
8.1
9.6
0.25
2.5
＜1000
0.75 to 1.5
4TB-9U
11
9.6
12.8
0.34
2.25
＜1500
2 to 3
4TB-11
11.5
12.8
16
0.34
2.25
＜2000
2.5 to 4
4TB-11U
11.5
9.6
16
0.34
2.25
＜2000
2.5 to 4
4TB-20
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-20U
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-34
20
19.05
22.2
0.34
2.25
＜6000
7.5 to 12
4TB-45
23
22.2
28.5
0.34
2.76
＜6000
5 to 15
25.6
28.5
34.9
0.34
2.76
＜6000
5 to 20


Working Principle:

Four Way Reversing Valve For Heat Pump Refrigeration Air Conditioner 220V 110V 24V 1


Structure:

Four Way Reversing Valve For Heat Pump Refrigeration Air Conditioner 220V 110V 24V 2


Our Production:
Four Way Reversing Valve For Heat Pump Refrigeration Air Conditioner 220V 110V 24V 3
