4TB-4U 4-Way Reversing Valve for HVAC Parts Heat Pump

4TB-4U 4-Way Reversing Valve for HVAC Parts Heat Pump

  • 4TB-4U 4-Way Reversing Valve for HVAC Parts Heat Pump
4TB-4U 4-Way Reversing Valve for HVAC Parts Heat Pump
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: None
Model Number: 4TB-4U
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: Negotiation
Payment Terms: T/T,Western Union,
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: 4 Way Reversing Valve D Port Size: 8.1mm (5/16'')
E.S.C Port Size: 9.6mm (3/8'') Power: 0.75 To 1.5HP
Applicable Refrigerant: R22, R407C, R410A, Etc Application: Heat Pump, Air Conditioning, Etc
Voltage: 24VDC, 24VAC, 110VAC, 220VAC
Highlight:

4TB-4U 4 way reversing valve

,

4TB-4U reversing valve

,

4-way reversing valve for heat pump

4TB-4U 4-Way Reversing Valve for HVAC Parts Heat Pump


The 4TB-4U 4-way reversing valve is a component used in compatible heat pump and HVAC systems to control refrigerant flow direction. Reversing valves enable heat pumps to switch between heating and cooling operation by changing the refrigerant circuit.


When selecting a 4TB-4U reversing valve, verify the model specifications, connection sizes, operating pressure, coil requirements, and compatibility with your equipment.

Refer to the manufacturer's technical documentation to confirm suitability for your application.

Contact our team for product details, technical specifications, and availability.


Technical Data:

Dimension - logo
Model No
Orifice Size
(mm)
Port Size
(mm)
Operating Pressure Difference (MPa)
Internal Leakage (ml/min)
P=1MPa at 70℃
Power
(HP)
D
E.S.C
Min
Max
4TB-4U
8
8.1
9.6
0.25
2.5
＜1000
0.75 to 1.5
4TB-9U
11
9.6
12.8
0.34
2.25
＜1500
2 to 3
4TB-11
11.5
12.8
16
0.34
2.25
＜2000
2.5 to 4
4TB-11U
11.5
9.6
16
0.34
2.25
＜2000
2.5 to 4
4TB-20
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-20U
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-34
20
19.05
22.2
0.34
2.25
＜6000
7.5 to 12
4TB-45
23
22.2
28.5
0.34
2.76
＜6000
5 to 15
25.6
28.5
34.9
0.34
2.76
＜6000
5 to 20


Working Principle:

Refrigeration 4 Way Reversing Valve For Heat Pump Air Conditioning 220V 110V 24V 1


Structure:

Refrigeration 4 Way Reversing Valve For Heat Pump Air Conditioning 220V 110V 24V 2


Our Production:
Refrigeration 4 Way Reversing Valve For Heat Pump Air Conditioning 220V 110V 24V 3
