FAL-35 Findeva Type Piston Pneumatic Air Vibrator for Hopper Bin

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	None
Model Number:	FAL-35

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	100000pcs per month

Contact Now

Detailed Product Description

Product Name:

Pneumatic Vibrator

Frequency:

1240 To 2010 VPM

Force:

205 To 655 N

Working Pressure:

2 To 6 Bar

Highlight:

FAL-35 Pneumatic Vibrator

FAL-35 Pneumatic Air Vibrator

Findeva FAL-35

FAL-35 Pneumatic Vibrator

FAL series vibrators are piston linear type, including FAL-8, FAL-18, FAL-25, FAL-35, FAL-50 models. Linear vibrating force is delivered by a noiseless air cushioned piston. Frequency and amplitude can be regulated independently. Common applications include natrual frequency feeders, small vibratory tables, screens, and hoppers where larger materials bridge. Not suitable for hoppers containing sticky or ratholing materials.

Technical Data:

FAL-35 Findeva Type Piston Pneumatic Air Vibrator for Hopper Bin

Model No	Frequency (V.P.M)		Force (N)		Air Consumption (l/min)
Model No	0.2MPa	0.6MPa	0.2MPa	0.6MPa	0.2MPa	0.6MPa
FAL-8	2050	3400	12	42	8	30
FAL-18	1420	2250	60	205	20	60
FAL-25	1130	2020	120	530	40	155
FAL-35	1240	2010	205	655	75	250

Main Dimension:

FAL-35 Findeva Type Piston Pneumatic Air Vibrator for Hopper Bin

Model No	A	B	C	D	E	F	G
FAL-8	91	25	27	20	M-6	M5	M5
FAL-18	117	50	33	48	M-10	G1/8''	G1/8''
FAL-25	139	65	40	60	M-16	G1/4''	G1/4''
FAL-35	140	80	37	80	M-16	G1/4''	G1/4''
