Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC

Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC

  • Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC
  • Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC
Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC
Product Details:
Place of Origin: China, Ningbo
Brand Name: BRANDO
Certification: CE, ISO
Model Number: GG20-M, GG25-M, GG32-M, GG40-M
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Irrigation Solenoid Valve Port Size: 3/4'', 1'', 1 1/4'', 1 1/2''
Orifice Size: 20mm, 25mm, 32mm, 40mm Pipe Connection: Female Threaded
Thread Type: G (Standard), BSP, NPT (Optional) Body Material: Plastic (Nylon)
Diaphragm Material: NBR (Standard), EPDM (Optional) Standard Coil Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Latching Coil Voltage: DC9-20V, Pulse Width (20-500mSec) Pressure Range: 1 To 10 Bar
Function: 2 Way Normally Closed Manual Flow Regulator: With
High Light:

Irrigation Solenoid Valve 12VDC

,

Irrigation Solenoid Valve 24VDC

,

Irrigation Solenoid Valve 24VAC

Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC



A water irrigation solenoid valve is an electrically controlled valve to regulate the flow of water. By applying a voltage over the coil, the valve opens and the liquid can flow through. They have a robust construction and are optionally equipped with manual flow control, so the desired flow can be adjusted. Most models have an override function, the valve can be opened manually if needed. Furthermore, they are equipped with a dirt particle filter. Our irrigation solenoid valves are available with a wide selection of control voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC.



Product Video of Irrigation Solenoid Valve:



Technical Data of Irrigation Solenoid Valve:

Model No
GG10
GG15
GG20
GG25
GG20-M
GG25-M
GG32-M
GG40-M
Manual Flow Regulator
Without
With
Orifice Size
10
15
20
25
20
25
32
40
Port Size
3/8''
1/2''
3/4''
1''
3/4''
1''
1 1/4''
1 1/2''
Max. Flow Range
2m³/h
3m³/h
5m³/h
9m³/h
5m³/h
9m³/h
15m³/h
21m³/h
Working Pressure Range
1 to 10 bar
Coil Voltage
Standard Coil: 220VAC, 110VAC, 24VAC (50/60Hz), 24VDC, 12VDC, 9VDC (Optional)
Latching Coil: DC9-20V, Pulse Width (20 to 500mSec)
Body Material
Plastic (Nylon)
Diaphragm Material
NBR (Standard), EPDM (Optional)
Operation
Diaphragm Pilot Operated



Main Dimension of Irrigation Solenoid Valve:

Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 0

Model Number
L
W
H
Without manual flow regulator
GG10
74mm
40mm
102mm
GG15
76mm
40mm
104mm
GG20
115mm
83mm
123mm
GG25
115mm
84mm
125mm
With manual flow regulator
GG20-M
114mm
83mm
133mm
GG25-M
115mm
84mm
135mm
GG32-M
135mm
96mm
156mm
GG40-M
136mm
97mm
167mm



More Irrigation Solenoid Valves for you to choose:

Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 1 Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 2 Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 3
3/8'' to 1'' 3/4'' to 1 1/2'' 2'' to 6''
Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 4 Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 5 Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 6
1 1/2'' to 2'' 3'' to 4''

3/4'' to 1 1/2''

(Normally Open)

Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 7 Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 8 Irrigation Solenoid Valve 3/4'' 1'' 1 1/4'' 1 1/2'' 12VDC 24VDC 24VAC 110VAC 220VAC 9
3'' to 10'' 3/4'' to 1 1/2''
(Pressure Reducing)
3/4'' to 1 1/2''
(Pressure Reducing)
