K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit
K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit

Product Details:

Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: GPC 10

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Turbo Pulse Valve Armature, Turbo Pulse Valve Plunger, Turbo Pulse Valve Stem Function: 2 Way, Normally Closed
Kind Of Current: AC, DC Armature Tube Material: Stainless Steel
Seal Insert Material: NBR Connection Type: M14x1 Thread
Fitted Pulse Valve: Turbo Pulse Valve
High Light:

Goyen Pulse Valve Plunger

,

Goyen K0380

,

Goyen K0580

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit



This is K0380 (M1131B) / K0580 (M1141B) solenoid kit for goyen pulse valve and solenoid valve repair kit. The related Goyen pulse jet valves, Goyen solenoid valves, solenoid coils and diaphragms are also supply. Welcome to your any inquiry and problem.



Features of Armature Assembly:



The main characteristics of the armature of solenoid valve can be reflected in the following aspects.

1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance

4. Sealing materials can be selected according to your different requirements

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection



Goyen Pulse Valve Armature:

Picture Dimension
Brando Model
BAPC212050501
Pulse Valve Armature 4 Pulse Valve Armature 5
Reference Number
K0380, M1131B
Plunger Tube Material
Stainless Steel
Seal Material
NBR
Voltage
AC, DC
Function
2 Way, Normally Closed
Fitted Coil
QR, QT2
Fitted Valve
Goyen Solenoid Valve



Picture Dimension
Model
QR
K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 2 K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 3
 Reference No
CY123, N282, C53056N
Voltage
24VDC, 220VAC
  Power 25VA, 20W
Fitted Armature Plunger
K0380 (M1131B),
K0580 (M1141B)
Fitted Valve
Goyen Pulse Valve



Picture Dimension
Model
QT2
K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 4 K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 5
Voltage
12VDC, 24VDC, 48VDC, 110VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
  Power 25VA, 20W
Fitted Armature Plunger
K0380 (M1131B),
K0580 (M1141B)
Fitted Valve
Goyen RCA3D Solenoid Valve


Brando Solenoid Valve Armature Production Video:

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 6



Related product supply:



* Solenoid Valve Coil:

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 7

* Diaphragm Repair Kit:

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 8



* Pulse Jet Valve:

K0380 M1131B K0580 M1141B Goyen Pulse Valve Repair Solenoid Kit 9
