300 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 3/8'' 24V 110V 220V

300 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 3/8'' 24V 110V 220V

  • 300 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 3/8'' 24V 110V 220V
300 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 3/8'' 24V 110V 220V
Product Details:
Place of Origin: China, Ningbo
Brand Name: BRANDO
Certification: CE, ISO
Model Number: SH
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: High Pressure Solenoid Valve Port Size: 1/4'', 3/8''
Orifice Size: 1mm To 5mm Working Medium: Air, Water, Gas, Liquid, Etc
Body Material: Stainless Steel 304 Seal Material: PTFE
Operation: Direct Acting Function: 2 Way Normally Closed
Max Working Pressure: 300 Bar Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

High Pressure Solenoid Valve 1/4''

,

High Pressure Solenoid Valve 3/8''

,

High Pressure Solenoid Valve 300 bar

300 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 3/8'' 24V 110V 220V



Product Features:

1. Working Medium: Air, Water, Gas, Liquid, etc
2. Max Working Pressure: 300 bar (See the parameter table below for details)
3. Seal Material: PTFE
4. Body Material: Stainless Steel 304
5. Port Size: 1/4'', 3/8'', 1/2'', 3/4'', 1''
6. Orifice Size: 1mm to 25mm
7. Operation: Direct Acting (DN1 to 5), Piston Pilot Operated (DN10 to 25)
8. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)



Ordering Code:

300 bar High Pressure Stainless Steel Solenoid Valve 1/4'' 3/8'' 24V 110V 220V 0



Technical Data:

Model No
Orifice Size
(mm)
Port Size
(inch)
CV
Working Pressure Range
(bar)
Dimension
Normally Closed
Normally Open
Normally Closed
220VAC
24VDC
AxBxC (mm)
SH-010ES
1
1/4'', 3/8''
0.04
0-300
0-150
0-150
44x25x80
SH-015ES
1.2
0.08
0-250
0-120
0-60
SH-020ES
2
0.15
0-180
0-70
0-35
SH-025ES
2.5
0.20
0-110
0-45
0-20
SH-030ES
3
0.25
0-80
0-40
0-15
SH-040ES
4
0.6
0-40
0-15
0-5
SH-050ES
5
0.9
0-25
0-8
/
SH-10ES
10
3/8''
3.5
6-160
6-120
6-50
60x55x109
SH-15ES
15
1/2''
4.7
70x65x119
SH-20ES
20
3/4''
7.0
80x74x124
SH-25ES
25
1''
11.0
90x87x134
