1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V

1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V

  • 1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V
1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V
Product Details:
Place of Origin: China, Ningbo
Brand Name: BRANDO
Certification: CE, ISO
Model Number: SH
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: High Pressure Solenoid Valve Working Medium: Air, Water, Gas, Liquid
Body Material: Stainless Steel Seal Material: PTFE
Operation: Direct Acting Function: 2 Way Normally Closed
Working Pressure Range: 0 To 300 Bar Port Size: 1/4'', 3/8''
Orifice Size: 1mm To 5mm Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
High Light:

High Pressure Solenoid Valve 1/4''

,

High Pressure Solenoid Valve 3/8''

,

Stainless Steel High Pressure Solenoid Valve

1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V



Features of SH Series High Pressure Solenoid Valve:

1. Working Medium: Air, Water, Gas, Liquid, etc
2. Working Pressure Range: 0 to 300 Bar (See the parameter table below for details)
3. Seal Material: PTFE
4. Body Material: Stainless Steel
5. Port Size: 1/4'', 3/8''
6. Orifice Size: 1mm to 5mm
7. Operation: 2 Way Normally Closed, Direct Acting
8. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC



Ordering Code of SH Series High Pressure Solenoid Valve:

1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V 0



Dimension and Data of SH Series High Pressure Solenoid Valve:

1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V 1 1/4'' 3/8'' Stainless Steel High Pressure Solenoid Valve 300 bar 24V 220V 2
DN1 to DN5 DN10 to DN15



Model
Orifice Size
(mm)
Port Size
(Inch)
CV
Working Pressure
(bar)
Dimension
Normally Closed
Normally Open
Normally Closed
220VAC
24VDC
AxBxC (mm)
SH-010ES
1
1/4'' or 3/8''
0.04
0-300
0-150
0-150
44x25x80
SH-015ES
1.2
0.08
0-250
0-120
0-60
SH-020ES
2
0.15
0-180
0-70
0-35
SH-025ES
2.5
0.20
0-110
0-45
0-20
SH-030ES
3
0.25
0-80
0-40
0-15
SH-040ES
4
0.6
0-40
0-15
0-5
SH-050ES
5
0.9
0-25
0-8
-
SH-10ES
10
3/8''
3.5
6-160
6-120
6-50
60x55x109
SH-15ES
15
1/2''
4.7
70x65x119
SH-20ES
20
3/4''
7
80x74x124
SH-25ES
20
1''
11
90x87x134



Product Video of High Pressure Solenoid Valve:



BRANDO Solenoid Valve Production Video:



More High Pressure Solenoid Valves for you to choose:



Brass Solenoid Valves
1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 2 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 3 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 4 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 5
MAX 50 bar MAX 50 bar MAX 50 bar MAX 50 bar
1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 6 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 7 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 8 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 9
MAX 50 bar MAX 70 bar MAX 120 bar MAX 200 bar





Stainless Steel Solenoid Valves
1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 10 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 11 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 12 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 13
MAX 50 bar MAX 50 bar MAX 50 bar MAX 100 bar
1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 14 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 15 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 16 1/4'' 3/8'' 1/2'' High Pressure Micro Stainless Steel Solenoid Valve 120 Bar 17
MAX 120 bar MAX 160 bar MAX 200 bar MAX 300 bar
