Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10

Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10

  • Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10
  • Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10
  • Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10
  • Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10
Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10
Product Details:
Place of Origin: China
Brand Name: OEM
Certification: ISO、CE
Model Number: 4V330-10
Payment & Shipping Terms:
Minimum Order Quantity: 3 pc
Price: negotiation
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Material: Aluminum Alloy Media: Air
Application: Automation Equipment Structure: Control
Connection: Thread(NPT Type: 5/3 Way Solenoid Valve
High Light:

cylinder operated valve

,

cylinder solenoid valve

Inner Pilot Type 4V300Series 5/3 Way Solenoid Pneumatic Valve 4V330-10



4V300 Series Solenoid Pneumatic Valves are popular in the market.You know its wide application.Detailed Feature as follow:Integral slot piston structure
Process valve hole with special high precision finishing process;Beautiful appearance;Good reverser;Reliable performance;Seal wear can automatic compensate.



Model No. 4V330-10
Fluid 40 micron Filtered Air
Action style Internal Pilot
Working pressure range 1.2Mpa
Ambient Temp 5~50’C
Voltage range ±10%
Power consumption AC:4.5VA DC:3W
Insulation and Protection Class F IP65
Insulation&Protection Class F.IP65



Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10 0

Pneumatic Cylinder

Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10 1



Inner Pilot Type 5/3 Way Pneumatic Solenoid Valve 4V300 Series 4V330-10 2



The advantages of 4V330-10

1, Double control solenoid valves have memory function.
2, Internal hole adopts special processing technology which has little
attrition friction ,low start pressure and long service life.
3, No need to add oil for lubrication.
4, It is available to from integrated valve group with the base to save
installation space.
5, Affiliated manual devices are equipped to facilitate installation and debugging
6, Several standard voltage grades are optional.
7. sliding column structure, good sealing, responsive;







Fault and Repair
First, the solenoid valve does not work after energizing.
Check whether power wiring is bad, re wiring and connector connection.
Check whether the supply voltage is within the range of + - to normal location.
Whether the coil is removed or re welded
Coil short circuit to replace coil
Is the working pressure difference inappropriate? Adjust the differential pressure to replace the equivalent solenoid valve.
The fluid temperature is too high to replace the proportionate solenoid valve.
Impurities jam the main valve core and the moving iron core of the solenoid valve for cleaning, if the seal is damaged, replace the seal and install the filter
The viscosity of the liquid is too high, the frequency is too high, and the life has arrived.
Two, solenoid valve can not be closed.
Seal of main spool or iron core has been damaged. Replace seal.
If the fluid temperature and viscosity are too high, replace the counterpart solenoid valves.
The impurity enters the electromagnetic valve to produce the valve core or the moving iron core.
The life of springs has arrived or deformed to replace.
Throttle hole balance hole clogging and timely cleaning
Working frequency is too high or life expectancy has changed.
Three, other circumstances
Internal leakage to check whether the seal is damaged, and whether the spring is assembled badly.
Leakage: connect loosening or seal is broken. Tighten screws or replace seals.
There is noise when power is switched on, and the fastener on the head is loose and tightened. Voltage fluctuation is not within the allowable range, adjust the voltage.

Clean or replace the impurities or uneven surfaces of the core.
