Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories

Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories

Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories

Product Details:

Place of Origin: Ningbo, China
Brand Name: BRANDO or OEM
Certification: CE, ISO
Model Number: BF001

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: negotiation
Packaging Details: PVC bag, inner box, carton, pallet
Delivery Time: 7 working days after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000000PCS PER MONTH
Contact Now
Detailed Product Description
Part Name: Fast Fitting Inner Claw Material: Acetal, Polypropylene, Brass
Size: 1/8" 1/4" 3/8" 1/2" Type: Quick Connecting, Push In Type
Application: Water Purification, Beverage, Pneumatic OEM: Yes
ODM: Yes



Food Grade Plastic Fast Fitting Inner Claw Used on Water Treatment Reverse Osmosis System


Types of Claw for your option:

Fast fitting inner claw, inner hand
Part No. Tube Size
BF001-A 1/4"
BF001-B 3/8"
BF001-C 1/2"



Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories



Specification of plastic claw for fast fitting:

1--Material: FDA & NSF certified POM plastic
2--Application :
Our quick fittings and connectors are widely used in water, beverage and food applications,
such as RO water filtration system, water treatment system, coffee maker, beverage machine,
refrigerator, vending machine, and so on.
3-- Leakage Proof Design: Have been proved in markets for years.
4-- Light weight, and easy to install.
5-- Color: white or grey body with blue locking clip.



Application example of fast fitting inner claw, inner hand:



Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories



Material Standards:

Material Options Fitting Color O-ring
Acetal Grey, Black, White NBR/EPDM
Polypropylene White NBR/EPDM
Brass Brass, or chromed NBR/EPDM



Fitting Working Pressure and Temperature:

  Small Size Large Size
  5/32" 3/16" 1/4" 5/16" 3/8" 1/2" 5/8" 7/8" 28mm
  4mm 5mm 6mm 8mm 10mm 12mm 15mm 16mm 18mm 22mm 28mm

1℃

34℉

16bar

230psi

11bar

170psi

11bar

170psi

20℃

68℉

16bar

230psi

11bar

170psi

11bar

170psi

65℃

150℉

10bar

150psi

7bar

100psi

7bar

100psi



Outer Diameter Tolerance Limit of Tubing Used with Fittings:

Size Tolerance
small size 5/32", 4mm +-0.004" (+-0.1mm)
small size 3/16", 5mm +-0.004" (+-0.1mm)
small size 1/4", 6mm +-0.004" (+-0.1mm)
small size 5/16", 8mm +-0.004" (+-0.1mm)
small size 3/8", 10mm +-0.004" (+-0.1mm)
small size 1/2", 12mm +-0.004" (+-0.1mm)
large size 5/8", 15(16)mm +-0.004" (+-0.1mm)
large size 7/8", 18(22)mm +-0.004" (+-0.1mm)
large size 28mm +-0.004" (+-0.1mm)



Maximum Permissible Torque:

      1/8", 1/4" 3/8", 1/2" 3/4"
Plastic Maximum Torque Nm 1.5 3.0 4.0
Steel Maximum Torque Nm 7.0-9.0 12.0-14.0 22.0-24.0 28.0-30.0 40.0





We aslo have many types quick fitting, push-in tube fitting, weclome your any question, we will response at once

Food Grade Plastic Fast Fitting Inner Claw for Water Treatment Reverse Osmosis Accessories
