Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder

China Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder supplier
Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder supplier Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder supplier

Large Image :  Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder

Product Details:

Place of Origin: NINGBO, CHINA
Brand Name: BRANDO or OEM
Certification: CE ISO
Model Number: CU

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: USD1.0--20.0 PER PC
Packaging Details: Bubble bag, wooden carton, pallet
Delivery Time: 7 working days after payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000PCS PER MONTH
Contact Now
Detailed Product Description
Part Name: CU Series Pneumatic Cylinder Material: SS304, Aluminum
Standard Or Non-standard: Standard Structure: Plunger Cylinder
Power: Pneumatic Acting Type: Double Acting

Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder



Product features:


1. Mounting dimensions comply with ISO(International standard),Non-lubricated(avoiding oil-

fog pollutioin);
2. Mainly made in aluminum alloy,light weight,small size
3. Cylinder tube and front and back cover are connected by male and female threads,can

dismouting and repaired;
4. The seal material with high temperature resistance is adopted to guarantee the normal

operation of cylinder are 150°C;
5. We offer the free samples for the buyer .



Parameters:

Bore Diameter 6 10 16 20 25 32
Acting Type Double acting/ Single acting spring return/ Single acting spring extend
Wroking Medium Clean air
Working pressure 1--7 bar
Guaranteed pressure 10 bar
Working temperature 5--60℃
Cushion type rubber cushion
Port Size M5x0.8 G 1/8





Internal Structure





Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder

No. Part Name Material
1 Nut Carbon steel
2 Piston rod Stainless steel
3 Piston rod seal NBR
4 Head cover Aluminum
5 Seal NBR
6 Piston seal TPU
7 Body Aluminum
8 Y shape seal NBR
9 Magnet
10 Piston Aluminum
11 Rear cover Aluminum
12 Clip Stainless Steel



Installation:

Airtac SMC Type Plunger Pneumatic Air Cylinders , Aluminum Air Cylinder
