13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve

13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve

    • 13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve
    • 13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve
    • 13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve
    • 13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve
    • 13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve
  • 13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve

    Product Details:

    Place of Origin: Ningbo, China
    Brand Name: BRANDO
    Certification: CE, ISO
    Model Number: BAPC313034044

    Payment & Shipping Terms:

    Minimum Order Quantity: 100pcs
    Price: USD0.10 to 1.00 PER PC
    Packaging Details: Inner box, carton, then packed by pallet
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 1million pcs per month
    Contact Now
    Detailed Product Description
    Part Name: Cng Solenoid Valve Stem Tube Diameter: 13mm
    Type: 2/2 Armature Plunger Material: 430FR
    Tube Material: Brass Application: CNG Solenoid Valve



    13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve





    Quick details of solenoid stem for CNG solenoid cylinder valve:

    1, can hold high pressure: 260bar

    2, made from brass solid bar

    3, can be working well at temperature from -40℃ to 85 ℃

    4, 2 way 2 way, normally closed

    Other type we also can produce as per your drawing or sample or detailed requirements



    Plunger and core are made by magnetic stainless steel specially designed for solenoid applications.

    The guide tube is made with brass, stainless steel is possible upon special agreement. The plunger is mormally quipped with NBR rubber seals. Other materials like viton are available upon request. The armature assembly is designed for more than 1 million cycles.



    CNG solenoid cylinder valve solenoid stem quick details:

    Part No. BAPC313034044
    Tube Diameter 13.00mm
    Height 34.00mm
    Tube Material brass solid bar
    Movable Plunger Material 430FR magnetic iron
    Spring Material SS304
    Seal Material NBR, EPDM, Silicone, Viton, all can be customized
    Type 2 way 2 way
    Working Voltage 12V DC 24V DC, 36V DC, 48V DC, 24V AC, 110V AC, 220V AC
    Weight 40 grams per set
    Packaging 40sets per box, 12boxes per carton, total 480sets per carton
    Carton Volume 0.02cbm
    Delivery Time One week after received payment
    Application cng solenoid valve
    OEM Yes, can produce as per your drawing or sample



    CNG solenoid cylinder valve solenoid stem overall dimensions:

    13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve



    We also could supply solenoid coil to match this CNG solenoid cylinder valve solenoid stem:

    13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve



    We have more than 10 years experience in manufacturing solenoid stem plunger set assembly of solenoid valves. Excellent quality control is one of our main principles. Our design, producing and testing are strictly complied with ISO9001 standard. Now our products of solenoid armature assembly are being exported all over the world. We provide OEM service, accept customer label, develop the product with your drawings or samples.If you have any question, contact us, we will be reply with prompt speed.



    How we select material to control the quality of solenoid stem plunger assembly set for solenoid valve:

    1, the static and movable core is made by rustproof and corrosion-resistant material with high magnetoconductivity and low remanence, and it is also durable and quick.

    2, the solenoid valve guide tube is made by H62 copper brass or SS304 stainless steel, and the thickness for selection is at the range of 0.25 t0 2.5mm.

    3, the seat of plunger tube is made by H59 copper or SS304

    4, adopting the laser solder technology makes the products more perfect and safe.

    5, the spring is made by imported stainless steel wire, which has good performance of pressure and restore.

    6, the sealant can be heatproof, oilproof and also can be exclusively applicable to food. All can do according to your requirements.

    7, the specification is including normally open, normally close, and AC DC voltage. If you have any other question just feel free to contact us.



    Our solenoid stem working shop:

    13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve



    The solenoid stem and solenoid coil on CNG solenoid cylinder valve:

    13mm Diameter Brass Tube Solenoid Stem For 12V DC / 24V DC CNG Cylinder Valve





    Welcome your any question of solenoid valve stem, armature, plunger set, we will response at once, and we also can produce as per your drawing or sample.
