Anti Corrosive Isolation Stainless Steel Solenoid Valve For Chemical Acid Alkali 1/8'' 1/4''

Anti Corrosive Isolation Stainless Steel Solenoid Valve For Chemical Acid Alkali 1/8'' 1/4''

Product Features:

1. Working Medium: Chemical, Acid, Alkali, Corrosive Liquids, etc
2. Working Pressure: 0 to 4 bar
3. Working Temperature: FFKM (-40 to +180ºC), FKM (-30 to +150ºC)
4. Port Size: 1/8'', 1/4''
5. Orifice Size: 2.5mm, 3mm, 3.5mm, 4mm
6. Body Material: Stainless Steel 304
7. Seal Material: FFKM, FKM
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
11. Application Examples: Analytical Instruments, Clinical Diagnostic Analyzers, Bio-Instrumentation, etc

Technical Data:

Main Dimension:

Our Production:

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
