| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | HS2 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Product Name: | High Pressure Solenoid Valve | Port Size: | 1/2'' |
|---|---|---|---|
| Pipe Connection: | Female Threaded | Thread Type: | G, NPT |
| Orifice Size: | 15mm | Operation: | Piston Pilot Operated |
| Function: | 2 Way Normally Closed | Body Material: | Stainless Steel 304 |
| Seal Material: | PTFE | Working Medium: | Water, Air, Gas, Liquid, Etc |
| Max Working Pressure: | 200 Bar | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz) |
| High Light: | 200 bar High Pressure Solenoid Valve,High Pressure Solenoid Valve 1/2'',High Pressure Solenoid Valve 24VDC |
||
1/2'' 200 bar High Pressure Stainless Steel Solenoid Valve 220VAC 110VAC 24VDC
Product Features:
1. Working Medium: Water, Air, Gas, Oil, Liquid, etc
2. Max Working Pressure: 200 bar (See the parameter table below for details)
3. Seal Material: PTFE
4. Body Material: Stainless Steel 304
5. Port Size: 1/8'', 1/4'', 3/8'', 1/2''
6. Orifice Size: 1.2mm, 2mm, 6mm, 10mm, 15mm
7. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting (1.2mm, 2mm orifice size), Piston Pilot Operated (6mm, 10mm, 15mm orifice size)
Technical Data:
Main Dimension:
 |
|
| 1/8'', 1/4'' (200 bar) | 1/4'', 3/8'' (100 bar) |
|
|
| 3/8'', 1/2'' (100 bar) | 1/2'' (200 bar) |
Production Video:
More High Pressure Solenoid Valves:
| Brass Solenoid Valves | |||
|
|
|
|
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 50 bar |
|
|
|
|
| MAX 50 bar | MAX 90 bar | MAX 120 bar | MAX 200 bar |
| Stainless Steel Solenoid Valves | |||
|
|
|
|
| MAX 50 bar | MAX 50 bar | MAX 50 bar | MAX 100 bar |
|
|
|
|
| MAX 120 bar | MAX 160 bar | MAX 200 bar | MAX 300 bar |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
