LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly

LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly

LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly
video
LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC210430740
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Position And Way: 2 Way 2 Position Non-working Status: Normally Closed
Seat Type: Thread Plunger Tube Material: Brass
Plunger Tube OD: φ10.3mm Seal Material: NBR
Voltage: AC, DC All Available Application EXamples: LPG / CNG Reducer, Solenoid Valve
High Light:

Gas Valve Armature Assembly

,

1203 -01MV Armature Assembly

,

PT.041 Solenoid Stem

LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly



This armature assembly is designed for LPG / CNG reducer solenoid valve. It is a moving part responsible for passing gas to the rest of the circuit, including 1 x brass plunger tube, 1 x stainless steel 304 moving core with NBR seal and 1 x stainless steel spring. The armature tube outer diameter is 10mm, so it is suitable to 10mm inner hole diameter solenoid valve coil. The standard plunger's seal material is VITON, but NBR, HNBR, EPDM, Silicone are all available to customize.



Technical data of Solenoid Valve Armature Assembly:

Model Number
BAPC210430740
Guide Tube Outer Diameter
10.3mm
Installation Height for Coil Assembling
29.5mm
Plunger Seal for Orifice Diameter
5.3mm
Guide Tube Material
Brass
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
Thread
Voltage
All range of AC and DC available
Position and Way
2/2 Way
Non-working Status
Normally Closed
Application Examples
LPG, CNG Reducer Solenoid Valve
Customized Service
Provided, welcome show us sample or drawing


Main dimension of Solenoid Valve Armature Assembly:

LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly 0

Details of Solenoid Valve Armature Assembly:

LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly 1

      2 Way Normally Closed                        Thread Seat

LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly 2

       Magnetic Moving Core                             NBR Seal



Brando Factory Production of Solenoid Valve Armature Assembly:



LPG CNG Automobile Gas Valve 1203 -01MV PT.041 Armature Assembly 3



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)



Product Features of Solenoid Valve Armature Assembly:


1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.



2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.



3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.



4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.



5 Shading ring:
Cooper and silver material available.



6. Washer and retaining nut provided if has demands.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
