| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 16CAF-S |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1'', 1 1/4'', 1 1/2'', 2'' | Orifice Size: | 25mm, 32mm, 40mm, 50mm |
|---|---|---|---|
| Operation Mode: | 2 Way Normally Closed | Operation: | Piston Pilot Operated |
| Body Material: | Stainless Steel | Working Medium: | Hot Water, Steam, Oil, Etc |
| Pressure Range: | 0.5 To 16 Bar | Seal Material: | PTFE, FKM |
| Temperature Range: | -60 To +200℃ (PTFE), -30 To +150℃ (FKM) | Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | Solenoid Steam Valve 220V,Solenoid Steam Valve 24V,SS304 Steam Solenoid Valve |
||
1'' 1 1/4'' 1 1/2'' 2'' Flanged Stainless Steel Solenoid Valve Steam 24V 220V
Product Features of Steam Solenoid Valve:
1. Working Medium: Hot Water, Steam, Oil, etc
2. Working Pressure Range: 0.5 to 16 Bar
3. Seal Material: PTFE, FKM
4. Body Material: Brass, Stainless Steel
5. Port Size: 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 25mm, 32mm, 40mm, 50mm
7. Operation: Piston Pilot Operated
8. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data of Steam Solenoid Valve:
Main Dimension of Steam Solenoid Valve:
Brando Factory Production of Solenoid Valves:
More Steam Solenoid Valves for you to choose:
| Brass Solenoid Valves | |||
|
|
|
|
|
|
|
|
| Stainless Steel Solenoid Valves | |||
|
|
|
|
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
