| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | SVD144 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Miniature Solenoid Valve | Rated Voltage: | 4.5V, 6V, 12V |
|---|---|---|---|
| Working Voltage Range: | 3.5-5.0V, 4.8-7.2V, 10.8-13.2V | Working Current: | ≤250, ≤320, ≤117 |
| Power Consumption: | ≤1.125, ≤1.96 ≤1.104 | DC Resistance: | 20±10%, 150±10% |
| Leakage: | ≤15mmHg / Min | Exhaust Speed: | 500CC /＜6S |
| High Light: | Miniature Solenoid Valve 12V,Miniature Solenoid Valve 6V,Miniature Solenoid Valve For Water |
||
Miniature Air Water Plastic Solenoid Valve 2 Way 3 Position 6V 12V
Miniature Solenoid Valves Application Examples:
1. Medical Equipments: Blood Pressure Monitor, Air Pressure Massage, Patient Monitor, etc.
2. Massage Health Care Equipments: Foot Massage, Massage Chair, Head and Eye Massage, Massage Bed, etc.
3. Household Appliances: Anti-snore Apparatus, Memory Pillow, Coffee Machine, Water Purifier, etc.
4. Other Applications: Kitchen and Bathroom Parts, Body Beauty Cares, Gas Detection and Analysis, Agricultural Application, and Scent Diffuse Machine, etc.
Dimension and Data of Miniature Plastic Solenoid Valve:
 |
|
|
Model
|
Rated
Voltage
|
Working Current
|
Power Consumption
|
Working Voltage Range
|
DC Resistance
|
Leakage
|
Exhaust Speed
|
|
SVD144-4.5
|
4.5V
|
≤250
|
≤1.125
|
3.5-5.0V
|
20±10%
|
≤15mmHg / Min
|
500CC /＜6S
|
|
SVD144-6
|
6V
|
≤320
|
≤1.96
|
4.8-7.2V
|
20±10%
|
||
|
SVD144-12
|
12V
|
≤117
|
≤1.104
|
10.8-13.2V
|
150±10%
|
Brando Solenoid Valve Factory Production Video:
More Miniature Plastic Solenoid Valves for you to choose:
| 2 Way Miniature Solenoid Valve | |||
|
|
|
|
|
|
|
|
| 3 Way Miniature Solenoid Valve | ||
|
|
|
|
|
|
| Combination | ||
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
