| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | GG50, GG65, GG80, GG100, GG125, GG150 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Irrigation Solenoid Valve | Port Size: | 2'', 2.5'', 3'', 4'', 5'', 6'' |
|---|---|---|---|
| Orifice Size: | 50mm, 65mm, 80mm, 100mm, 125mm, 150mm | Pipe Connection: | Female Threaded (Standard), Flanged (Optional) |
| Thread Type: | G (Standard), BSP, NPT (Optional) | Body Material: | Plastic (Nylon) |
| Diaphragm Material: | NBR (Standard), EPDM (Optional) | Standard Coil Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| Latching Coil Voltage: | DC9-20V, Pulse Width (20-500mSec) | Pressure Range: | 1 To 10 Bar |
| Function: | 2 Way Normally Closed | Manual Flow Regulator: | With |
| High Light: | Plastic Irrigation Water Solenoid Valve,12V Irrigation Solenoid Valve,24V Irrigation Solenoid Valve |
||
Plastic Irrigation Water Solenoid Valve 2'' 2 1/2'' 3'' 4'' 5'' 6'' 12V 24V
A water irrigation solenoid valve is an electrically controlled valve to regulate the flow of water. By applying a voltage over the coil, the valve opens and the liquid can flow through. They have a robust construction and are optionally equipped with manual flow control, so the desired flow can be adjusted. Most models have an override function, the valve can be opened manually if needed. Furthermore, they are equipped with a dirt particle filter. Our irrigation solenoid valves are available with a wide selection of control voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC.
Product Video of Irrigation Solenoid Valve:
Technical Data of Irrigation Solenoid Valve:
|
Model
|
GG50
|
GG65
|
GG80
|
GG100
|
GG125
|
GG150
|
|
Orifice Size
|
50
|
65
|
80
|
100
|
125
|
150
|
|
Port Size
|
2''
|
2 1/2''
|
3''
|
4''
|
5''
|
6''
|
|
Max. Flow Range
|
60m³/h
|
65m³/h
|
70m³/h
|
120m³/h
|
125m³/h
|
210m³/h
|
|
Pipe Connection
|
Female Threaded (Standard), Flanged (Optional)
|
|||||
|
Working Pressure Range
|
1 to 10 bar
|
|||||
|
Coil Voltage
|
Standard Coil: 220VAC, 110VAC, 24VAC (50/60Hz), 24VDC, 12VDC, 9VDC (Optional)
Latching Coil: DC9-20V, Pulse Width (20 to 500mSec)
|
|||||
|
Body Material
|
Plastic (Nylon)
|
|||||
|
Diaphragm Material
|
NBR (Standard), EPDM (Optional)
|
|||||
|
Operation
|
Diaphragm Pilot Operated
|
|||||
|
Manual Flow Regulator
|
With
|
|||||
|
Length
|
232mm
|
250mm
|
299mm
|
355mm
|
360mm
|
485mm
|
|
With
|
135mm
|
136mm
|
137mm
|
220mm
|
233mm
|
247mm
|
|
Height
|
215mm
|
222mm
|
230mm
|
322mm
|
330mm
|
365mm
|
