Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | PS-25J |
Minimum Order Quantity: | 1 pc |
---|---|
Price: | Negotiation |
Packaging Details: | Inner boxes, Carton, Pallet |
Delivery Time: | 4-8 days |
Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
Supply Ability: | 100000 pcs per month |
Port Size: | 1'' | Orifice Size: | 25mm |
---|---|---|---|
Operation Mode: | 2 Way, Normally Closed | Operation: | Piston Pilot Operated |
Body Material: | Stainless Steel 304 | Seal Material: | PTFE |
Working Medium: | Steam, Hot Water, High Temp Liquid | Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
Pressure Range: | 0.4 To 16 Bar | Temperature Range: | 0 To +180℃ |
High Light: | Steam Solenoid Valve 1'',Steam Control Solenoid Valve,Steam Solenoid Valve 120V |
1'' Stainless Steel Steam Control Electric Solenoid Valve 24VDC 220VAC
Product Features:
1. Working Medium: Steam, High Temperature Liquid, etc.
2. Working Meidum Temperature Range: 0 to +180℃
3. Working Pressure Range: 0.1 to 16 bar
4. Function, 2 Way Normally Closed, 2 Way Normally Open
5. Operation: Piston Pilot Operated
6. Body Material: Brass, Stainless Steel
7. Seal Material: PTFE
8. Port Size: 1/4'', 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
9. Thread Type: G, NPT
10. Supply Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Main Dimension of Solenoid Valve:
Technical Data of Solenoid Valve:
Brando Factory Production of Solenoid Valves:
More Stainless Steel Solenoid Valves for you to choose:
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
