Name: 2S160-10-NO 3/8'' Two Ways NO Stainless Steel Water Solenoid Valve 24V
Brand: Brando
SKU: 2S160-10-NO
Rating: 4.9 (172 reviews)

Home Products Stainless Steel Solenoid Valve

2S160-10-NO 3/8'' Two Ways NO Stainless Steel Water Solenoid Valve 24V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2S160-10-NO

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	3/8''	Orifice Size:	16mm
Operation Mode:	2 Way, Normally Open	Action:	Direct Lifting Diaphragm
Working Fluids:	Air, Water, Oil, Gas	Body Material:	Stainless Steel 304
Seal Material:	NBR	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0 To 1 MPa	Temperature Range:	-5 To +80 ℃
High Light:	3/8'' Water Solenoid Valve , Solenoid Valve Two Ways , Solenoid Valve For Water

2S160-10-NO 3/8'' Two Ways NO Stainless Steel Water Solenoid Valve 24V

Normally open solenoid valves stay open unless energized. When energy is applied, they immediately close, and stay that way as long as energized. Because of the way they close, these are not intended for continuous use of more than a few hours. They are a great choice for situations where a valve needs to only close for short spurts, and should remain open most of the time.

Main Dimension of Solenoid Valve:

2S160-10-NO 3/8'' Two Ways NO Stainless Steel Water Solenoid Valve 24V 0

Model	Port Size	A	B	C
2S025-06	1/8''	35	35	76
2S025-08	1/4''	35	35	76
2S040-10	3/8''	44	44	88
2S160-10	3/8''	66	56	103
2S160-10-NO				125
2S160-15	1/2''	66	56	103
2S160-15-NO				125
2S200-20	3/4''	73	56	110
2S200-20-NO				132
2S250-25	1''	98	73	117
2S250-25-NO				139
2S350-35	1 1/4''	118	93	160
2S350-35-NO				180
2S400-40	1 1/2''	118	93	160
2S400-40-NO				180
2S500-50	2''	156	124	188
2S500-50-NO				209

Technical Data of Solenoid Valve:

Medium	Air, Water, Oil, Gas
Action	Direct Acting, Direct Lifting Diaphragm
Function	2 Way, Normally Closed (NC), Normally Open (NO)
Viscocity	20 cst Below
Pressure	Normally Closed (0 to 1MPa), Normally Open (0 to 0.8MPa)
Temperature	NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃, Silicone: -15 to +150℃
Body Material	Stainless Steel 304
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Type	Waterproof Coil, Round Coil, Square Coil, etc.
