Name: 2L-20 Stainless Steel Steam Solenoid Valve 3/4 Inch 24VDC 220VAC
Brand: Brando
SKU: 2L-20
Rating: 4.9 (106 reviews)

Home Products Stainless Steel Solenoid Valve

2L-20 Stainless Steel Steam Solenoid Valve 3/4 Inch 24VDC 220VAC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2L-20

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	3/4''	Orifice Size:	17mm
Operation Mode:	2 Way, Normally Closed	Action:	Piston Piloted Operated
Working Fluids:	Hot Water, Steam	Body Material:	Brass, Stainless Steel
Seal Material:	PTFE	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0.1 To 1.5 MPa	Temperature Range:	-20 To +185 ℃
High Light:	Solenoid Valve 2L-20 , Stainless Steel Steam Solenoid Valve , Steam Solenoid Valve 3/4 Inch

2L-20 Stainless Steel Steam Solenoid Valve 3/4 Inch 24VDC 220VAC

We are offering 2l series solenoid valve. the thread size of 2/2 way pilot steam solenoid valves range from 3/8'' to 2''. It can work under 180 ℃, mainly used for controlling the steams, that's why called the steam solenoid valve. The working pressure for this solenoid valve is high, which can reach 1.5 MPa. The orifice sizes for this valve is also bigger than normal valve for same thread sizes to make the flow rate bigger. With its steady performance, this type of solenoid valve is widely used in the steam control systems in different countries.

Main Dimension of Steam Solenoid Valve:

2L-20 Stainless Steel Steam Solenoid Valve 3/4 Inch 24VDC 220VAC 0

US Series	2L Series	A	B	C	Port Size
US-10	2L-10	82	42	146	3/8''
US-15	2L-15				1/2''
US-20	2L-20				3/4''
US-25	2L-25	90	54	162	1''
US-35	2L-35	110	75	185	1 1/4''
US-40	2L-40	110	75	185	1 1/2''
US-50	2L-50	120	77	195	2''

Technical Data of Steam Solenoid Valve:

2L Series	2L-10	2L-15	2L-20	2L-25	2L-35	2L-40	2L-50
US Series	US-10	US-15	US-20	US-25	US-35	US-40	US-50
Orifice Size	17	17	17	22	30	30	50
Port Size	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Hot Water, Steam
Action	Direct Acting, Servo Pilot Operated
Function	2 Way, Normally Closed
Body Material	Brass, Stainless Steel
Seal Material	PTFE, FKM
Pressure Range	0.1 to 1.5 MPa
Temp. Range	PTFE: -20 to +185℃, FKM: -10 to +150℃
Coil Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
