Name: 2S025-08 SUS-8 1/4'' Inch Thread Stainless Steel Solenoid Valve
Brand: Brando
SKU: 2S025-08
Rating: 4.7 (130 reviews)

Home Products Stainless Steel Solenoid Valve

2S025-08 SUS-8 1/4'' Inch Thread Stainless Steel Solenoid Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2S025-08

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Valve Series:	2S Series	Ref. Number:	UNI-D Type SUS-08
Voltage:	AC110V AV220V DC24V	Action:	Direct Acting
Port Size:	1/4''	Media:	Water Air Gas
Fluid Viscossity:	Below 20 CST	Power:	Solenoid
Body Material:	Stainless Steel	Diaphragm Material:	NBR, FKM And EPDM
High Light:	2S025-08 Stainless Steel Solenoid Valve , SUS-8 Stainless Steel Solenoid Valve , UNI-D Type 2S025-08 SUS-8

2S025-08 SUS-8 1/4'' Inch Thread Stainless Steel Solenoid Valve

This is a 2W025-08 mini solenoid valve, 1/4 inch (G, NPT) female thread port size, stainless steel 304 body material, NBR seal material, 2 way normally closed, direct acting, 12V DC, 24V DC, 110V AC, 120V AC, 220V AC, 230V AC voltages for you to choose, other voltages can be customized.

2S series stainless steel solenoid valve: 2S025-06, 2S025-08, 2S040-10, 2S160-10, 2S160-15, 2S200-20, 2S250-25, 2S350-35, 2S400-40, 2S500-50.

2W series brass solenoid valve: 2W025-06, 2W025-08, 2W040-10, 2W160-10, 2W160-15, 2W200-20, 2W250-25, 2W350-35, 2W400-40, 2W500-50.

Technical Data of 2W & 2S Solenoid Valve:

2W Series	2W025-08	2W040-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
2S Series	2S025-08	2S040-10	2S160-15	2S200-20	2S250-25	2S350-35	2S400-40	2S500-50
Orifice Size	2.5	4	15	20	25	35	40	50
Port Size	1/4''	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Water, Air, Gas, Oil
Action	Direct Acting		Semi-Direct Diaphragm Operated
Function	2 Way, Normally Closed
Fluid Viscosity	20 CST below
Pressure Range	0 to 1.0 Mpa
Temp. Range	-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
2S025-08 SUS-8 1/4'' Inch Thread Stainless Steel Solenoid Valve 0

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	1/8''
2S025-08	2W025-08	64.5	30	75	43	1/4''
2S040-10	2W040-10	70.6	32	82.4	53	3/8''
2S160-10	2W160-10	101.5	57	117	69	3/8''
2S160-15	2W160-15	101.5	57	117	69	1/2''
2S200-20	2W200-20	107	57	123.5	73	3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	1''
2S350-35	2W350-35	142	95	172	123	1-1/4''
2S400-40	2W400-40	142	95	172	123	1-1/2''
2S500-50	2W500-50	172	123	209	168	2''

Features:
1.Direct-Acting, conductive, normally closed.
2.Valve body material is Stainless steel.
3.Can be operated directly without pressure.
4.Small size and easy assembly.
5.Standard voltage : 24VDC,110VAC, 220VAC AC Voltage tolerance: ± 10% ,
DC Voltage tolerance:±1%.
6.Other special AC/DC can be made to client's order.
7.Thread: BSPT, NPT , BSP.
8.The standard product fluid temperature is 80°C(NBR).
9.Temperature:Viton(130°C), Silicon(130°C), PTFE(185°C).
10. DIN43650A connector Coil is interchangeable
