Name: 3/4'' Inch Semi-Diaphragm Brass UW-20 SS304 SUW-20 Solenoid Valve
Brand: Brando
SKU: 2S200-20
Rating: 4.5 (183 reviews)

Home Products Stainless Steel Solenoid Valve

3/4'' Inch Semi-Diaphragm Brass UW-20 SS304 SUW-20 Solenoid Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2S200-20

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Valve Series:	2S Series	Ref. Number:	UNI-D Type SUW-20
Voltage:	AC110V AV220V DC24V	Action:	Pilot Diaphragm
Port Size:	3/4 '' Inch	Media:	Water Air Gas
Fluid Viscossity:	Below 20 CST	Power:	Solenoid
Body Material:	Stainless Steel	Diaphragm Material:	NBR, FKM And EPDM
High Light:	3/4'' Inch Solenoid Valve , SUW-20 Solenoid Valve , Uni-D Type UW-20 SUW-20

3/4'' Inch Semi-Diaphragm Brass UW-20 SS304 SUW-20 Solenoid Valve

2S200-20 is an electromagnetic valve, stainless steel, appropriate is used in the field of circulation time longer control, adopting direct acting diaphragm structure, the body is made of stainless steel, corrosion resistant function.It adopts a diaphragm structure and has the characteristics of quick opening and closing, stable performance, convenient use, high reliability and long service life. The water-using solenoid valve has strong anti-pollution ability. It can be used for a long time in rivers, rivers, lakes, oceans and various artificial waters.

2S200-20

2S:2 Position 2 Way Direct Drive Solenoid Valve With Stainless Steel Body.

200: The Aperture of Flow Rate is 20 mm

20: The Port Size is G 3/4 ''

Technical Data of 2W & 2S Solenoid Valve:

2W Series	2W025-08	2W040-10	2W160-15	2W200-20	2W250-25	2W350-35	2W400-40	2W500-50
2S Series	2S025-08	2S040-10	2S160-15	2S200-20	2S250-25	2S350-35	2S400-40	2S500-50
Orifice Size	2.5	4	15	20	25	35	40	50
Port Size	1/4''	3/8''	1/2''	3/4''	1''	1-1/4''	1-1/2''	2''
Medium	Water, Air, Gas, Oil
Action	Direct Acting		Semi-Direct Diaphragm Operated
Function	2 Way, Normally Closed
Fluid Viscosity	20 CST below
Pressure Range	0 to 1.0 Mpa
Temp. Range	-5 to +85℃

Main dimension of 2W & 2S Series Solenoid Valves:
3/4'' Inch Semi-Diaphragm Brass UW-20 SS304 SUW-20 Solenoid Valve 0

2S Series	2W Series	A	B	C	D	E
2S025-06	2W025-06	64.5	30	75	43	1/8''
2S025-08	2W025-08	64.5	30	75	43	1/4''
2S040-10	2W040-10	70.6	32	82.4	53	3/8''
2S160-10	2W160-10	101.5	57	117	69	3/8''
2S160-15	2W160-15	101.5	57	117	69	1/2''
2S200-20	2W200-20	107	57	123.5	73	3/4''
2S250-25	2W250-25	111.5	73.5	134.5	99	1''
2S350-35	2W350-35	142	95	172	123	1-1/4''
2S400-40	2W400-40	142	95	172	123	1-1/2''
2S500-50	2W500-50	172	123	209	168	2''

Stainless steel solenoid valve characteristics:

1) The protection grade for this series solenoid valve is IP67.
2) These valves are made of stainless steel and can work in corrosive environments.
3) Pressure unit: 1kgf/cm2=1bar=0.1MPa=100KPa=14.5psi
4) The working temperature for Viton or PTFE can reach -20℃~169℃.
5) Different thread types can be offered according to customers' requirements, e.g.: G, PT, NPT etc.
