SMC Type CXSWM25-100 Double Guide Rod Air Cylinder Double Action

SMC Type CXSWM25-100 Double Guide Rod Air Cylinder Double Action

Guide Pneumatic Cylinders are actuators that incorporate the guide and cylinder into a single unit. A guide mechanism needs to be provided since piston rods can bend, rotate or buckle in response to forces such as lateral loads. Using a cylinder with a guide eliminates the need to provide a separate guide mechanism, improving accuracy and rigidity while saving space. The available guide types include linear guides used in combination with the cylinder, and twin rod cylinders that have 2 air-pressure cylinders incorporated into a single unit. When selecting cylinders with guides, the type should be selected to match the objective (positioning, direct diversion, lifting or the like). Other factors to consider when making the selection include the cylinder diameter, stroke and mounting method, as well as the installation location of the mounted equipment (such as a cleanroom or food processing plant).

Specifications of CXSW Series Pneumatic Cylinder:

Stroke of CXSW Series Pneumatic Cylinder:

Ordering Code of CXSW Series Pneumatic Cylinder:

Theoretical Output of CXSW Series Pneumatic Cylinder:

Brando Supply Pneumatic Air Cylinders:

Airtac Type Pneumatic Cylinder	Festo Type Pneumatic Cylinder	SMC Type Pneumatic Cylinder

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
