Double Acting Pneumatic Compact Cylinder Festo Type ADVU-32-50-P-A

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	ADVU

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-7 work days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Product Series:	Compact Cylinder	Bore Size (mm):	12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125
Standard Stroke (mm):	5, 10, 15, 20, 25, 30, 40, 50, 60, 80	Acting Type:	Double Acting
End Of Piston Rod:	Female Thread, Male Thread	Thread Sizes:	M3, M4, M5, M6, M8, M10, M12, M16, M10x1.25, M12x1.25, M16x1.5, M20x1.5, M27x2
Operating Medium:	Compressed Air
High Light:	Double Acting Pneumatic Compact Cylinder , Festo Pneumatic Compact Cylinder , Festo ADVU-32-50-P-A

Double Acting Pneumatic Compact Cylinder Festo Type ADVU-32-50-P-A

Pneumatic Air Cylinders are either single-acting (spring return or spring extent) or double-acting. Single-acting cylinders require compressed to either extend or return the piston and the spring force is in the opposite direction. In a double-acting cylinder, compressed air is used for both the extension and retraction of the rod depending on where the high pressure is.Double acting cylinders are most commonly used. With multiple different configurations of rod diameter, stroke length, force in/out, and pressure ranges there is a pneumatic cylinder for almost any application requiring linear motion. We also have options with a magnetic piston for position feedback capabilities as well as adjustable damping for added control of cushioning.

BRANDO’s wide range of pneumatic cylinders allow you to find a product to meet almost any application requirements and we ensure they are made from high quality material, tested, calibrated, and come to you at a competitive price.

Technical Data of ADVU Series Compact Pneumatic Cylinder:

Double Acting Pneumatic Compact Cylinder Festo Type ADVU-32-50-P-A 0

Double Acting Pneumatic Compact Cylinder Festo Type ADVU-32-50-P-A 1

Stroke of ADVU Series Compact Pneumatic Cylinder:

Bore (mm)		Standard Stroke (mm)	Max. Std Stroke (mm)
ADVU	12	5 10 15 20 25 30 40	1 ~ 200
	16	5 10 15 20 25 30 40	1 ~ 200
	20	5 10 15 20 25 30 40 50	1 ~ 200
	25	5 10 15 20 25 30 40 50	1 ~ 200
	32	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	40	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	50	10 15 20 25 30 40 50 60 80	1 ~ 300
	63	10 15 20 25 30 40 50 60 80	1 ~ 300
	80	10 15 20 25 30 40 50 60 80	1 ~ 400
	100		1 ~ 400
	125		1 ~ 400
ADVULQ	12	5 10 15 20 25 30 40	1 ~ 200
	16	5 10 15 20 25 30 40	1 ~ 200
	20	5 10 15 20 25 30 40 50	1 ~ 200
	25	5 10 15 20 25 30 40 50	1 ~ 200
	32	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	40	5 10 15 20 25 30 40 50 60 80	1 ~ 300
	50	10 15 20 25 30 40 50 60 80	1 ~ 300
	63	10 15 20 25 30 40 50 60 80	1 ~ 300
	80	10 15 20 25 30 40 50 60 80	1 ~ 400
	100		1 ~ 400
	125		1 ~ 400

Ordering Code of ADVU Series Compact Pneumatic Cylinder:

Double Acting Pneumatic Compact Cylinder Festo Type ADVU-32-50-P-A 2
