| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | DNC |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 work days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Series: | Piston Rod Cylinder | Bore Size (mm): | 32, 40, 50, 63, 80, 100, 125 |
|---|---|---|---|
| Standard Stroke (mm): | 25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 | Acting Type: | Double Acting |
| Operating Pressure Range: | 0.15 To 1.0 MPa | Proof Pressure: | 1.5 MPa |
| High Light: | Adjustable Cushion Air Cylinder,Festo Air Cylinder,Festo DNC-50-200-PPV-A |
||
Adjustable Cushion Pneumatic Air Cylinder Festo Type DNC-50-200-PPV-A
Pneumatic cylinders, also known as pneumatic actuators, operate by using the force of compressed air against a moving piston to create mechanical movement. Pneumatic cylinders are specified depending on the mass of the load being moved, the distance it is to be moved over and the time required to move the load.
Single acting and double acting pneumatic cylinders are the common options available. In single-acting pneumatic cylinders, air forces the piston against a spring which returns the cylinder to its default position when the air is removed. In double-acting pneumatic cylinders, air is used to push the piston one way and to return the cylinder to its default position. Air is applied on the opposite side of the piston while on the original side and the air is allowed to exhaust.
Specifications of DNC Series Pneumatic Cylinder:
| Bore Size (mm) | 32 | 40 | 50 | 63 | 80 | 100 | 125 | ||
| Acting Type | Double Acting | ||||||||
| Fluid | Air (to be filtered by 40μm filter element) | ||||||||
| Operating Pressure Range | 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi) | ||||||||
| Proof Pressure | 1.5 MPa (15 bar) (215 psi) | ||||||||
| Temprature (℃) | -20 to +80 | ||||||||
| Speed Range (mm/s) | 30 to 800 | ||||||||
| Cushion Type | Variable cushion | ||||||||
| Port Size | 1/8'' | 1/4'' | 3/8'' | 1/2'' | |||||
Stroke of DNC Series Pneumatic Cylinder:
| Bore Size (mm) | Standard Stroke (mm) | Max. Std Stroke | Max. Stroke |
| 32 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500 |
1000 | 1800 |
| 40 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800 |
1200 | 1800 |
| 50 |
25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000 |
1200 | 1800 |
| 63 | 1500 | 1800 | |
| 80 | 1500 | 1800 | |
| 100 | 1500 | 1800 | |
| 125 | 1500 | 1800 |
Ordering Code of DNC Series Pneumatic Cylinder:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
